Extreme Brocade BR-SLX-9140-48V-AC-F 48x 25GB SFP28 6x QSFP28 F-B Air Switch

Extreme Brocade BR-SLX-9140-48V-AC-F 48x 25GB SFP28 6x QSFP28 F-B Air Switch

$ 2,587.99
Only 1 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: Seller refurbished
Pre-owned, tested by qualified techs, working, reset-to-factory default, grade A condition, and parts needed for normal functions are included (as described in the listing).
Warranty: 365 days
Warranty coverage period
SKU: NSB-4667

Overview

The Extreme Brocade BR-SLX-9140-48V-AC-F switch is a high-performance networking device designed for data-intensive environments. Its 48x 25GB SFP28 and 6x QSFP28 front-to-back airflow offer excellent connectivity.

This switch has an impressive switching capacity of 1.8 Tbps in both incoming and outgoing traffic directions, resulting in a total of 3.6 Tbps throughput capability. It can handle large amounts of network traffic with ease.

The BR-SLX-9140 provides line-rate performance at (L2)1.2 Bpps and (L3)600 Mpps, respectively, ensuring smooth data transfer even during peak usage periods.

With support for up to an extensive MAC address table size limit Up to 96,000 addresses), this switch allows efficient management and communication within your network infrastructure.

Extreme Brocade BR-SLX-9140-48V-AC-F: SLX 9140-48V switch AC with front-to-back airflow.


Specifications

  • Network Ports : 48x 25 Gigabit Ethernet SFP28
  • Uplink Ports : 6x 100 Gigabit Ethernet QSFP28
  • Management Ports : 1x RJ45 Out of Band Management, 1x RJ45 Console Management, 1x USB Serial Type C, 1x USB Type A
  • Fan Modules AirFlow Direction : 5x Field Replaceable Fans Included - Front to Back Airflow
  • Power Supplies Included : 2x Internal, Field Replaceable, Redundant Load Sharing AC PSU's Included
  • Switching Capacity : 1.8 Tbps in and 1.8 Tbps out for a sum total of 3.6 Tbps
  • Forwarding Rate : (L2) 1.2 Bpps, (L3) 600 Mpps line-rate performance
  • MAC Address Table Size : Up to 96,000
  • Latency : 2.5 usec
  • Rack Mounts : Included (1-RU)
  • Model Number : BR-SLX-9140-48V-AC-F
  • Part Number : BR-SLX-9140-48V-AC-F
  • Condition : Seller refurbished


Included

  • One (1) Seller Refurbished Extreme Brocade BR-SLX-9140-48V-AC-F ExtremeSwitching SLX 9140 Series 48x 25 Gigabit SFP28 6x 100 QSFP28 Front-to-Back Airflow Switch as described above
  • Two (2) Power Cords Included
  • Two (2) AC Power Supplies Included
  • Five (5) Fan Modules Included
  • One (1) Set of Rack Mount Brackets Included

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
  • Transceiver Modules Not Included
