NEW Extreme 17350 X690-48x-2q-4c 48x 10GB SFP+ 2x 40GB QSFP+ 4x QSFP28 Switch
New

NEW Extreme 17350 X690-48x-2q-4c 48x 10GB SFP+ 2x 40GB QSFP+ 4x QSFP28 Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-3825
UPC: 644728173501

Overview

The NEW Extreme 17350 X690-48x-2q-4c Switch offers high-capacity switching with a capacity of 1.76 Tbps and a forwarding rate of 759 Mpps. With support for up to 272,000 MAC addresses, this switch provides efficient networking solutions for large-scale deployments.

The latency averages at just 800 ns, ensuring smooth data transmission within the network. Equipped with 48x10GB SFP+, as well as dual QSFP+ ports and quad QSFP28 ports, this switch can easily handle heavy workloads while maintaining reliable connectivity.

Whether used in data centers or enterprise environments that require fast and seamless communication between devices, the Extreme X690 series is designed to meet these demands efficiently.

NEW Extreme 17350 X690-48x-2q-4c 48x 10GB SFP+ 2x 40GB QSFP+ 4x QSFP28 Switch


Specifications

  • Network Ports : 48x 10 Gigabit Ethernet SFP+
  • Uplink Ports : 48x 10 Gigabit Ethernet SFP+, 2x 40 Gigabit Ethernet QSFP+, 4x 100 Gigabit Ethernet QSFP28
  • Management Ports : 1x Micro USB, 1x Out of Band RJ45 Management, 1x Serial Console,
  • Fan Module Options : 6x Unpopulated Fan Module Slots - Options are 17115 (Front to Back), 17116 (Back to Front)
  • Power Supplies Included : 2x Unpopulated Power Supply Slots
  • Power Supply Options : 10960 (770W AC PSU F-B), 10961 (770W AC PSU B-F), 10962 (1100W DC PSU F-B), 10963 (1100W DC PSU B-F) - Not Included
  • Switching Capacity : 1.76 Tbps
  • Forwarding Rate : 759 Mpps
  • MAC Address Table Size : 272,000
  • Average Latency : 80 0 ns
  • Model Number : 17350
  • Part Number : X690-48X-2Q-4C, 17350
  • Condition : New


Included

  • One (1) NEW Extreme 17350 X690-48x-2q-4c 48x 10GB SFP+ 2x 40GB QSFP+ 4x QSFP28 Switch as described above
