The NEW Cisco C9200-24P-A is a high-performance switch for small to medium-sized networks. With 24 PoE+ RJ45 ports and one module slot, this switch offers flexibility regarding connectivity options.
One notable feature of the C9200-24P-A is its Power over Ethernet (PoE) capability, providing power and network connectivity to devices such as IP cameras or wireless access points through a single cable. The switch has a total PoE budget of 370W with one power supply unit (PSU), which can be doubled to 740W with two PSUs.
The C9200-24P-A boasts a switching capacity of up to 128 Gbps when used standalone or an impressive 288 Gbps when stacked with other compatible switches. It also delivers fast forwarding rates at approximately 190.4 Mpps individually or up to 175 Mpps during stacking sessions
NEW Cisco C9200-24P-A 24x 1GB PoE+ RJ45 1x Module Slot Switch
- Network Ports : 24x 1 Gigabit Ethernet PoE+ RJ45
- SMARTnet : If you are planning to put this under SMARTnet, please ask before purchasing. We cannot guarantee that the unit will be SMARTnet eligible unless checked prior to purchase.
- Management Ports : 1x RJ45 Console, 1x Gigabit Management, 2x USB, 1x Mini USB
- Stacking Ports : StackWise-160 possible through the use of C9200-STACK-KIT - Ordered Separately - Stacking Bandwidth = 160 Gbps | This switch cannot be stacked with fixed C9200 models or other Catalyst switches.
- Stacking Cable Options : STACK-T4-50CM (Default with C9200-STACK-KIT), STACK-T4-1M, STACK-T4-3M - Not Included
- Module Slots : 1x Expansion Module Slot - Module not Included
- Module Options : C9200-NM-4G (4x 1GB SFP) , C9200-NM-4X (4x 1G/10G SFP), C9200-NM-BLANK - None Included - Ordered Separately
- Switch Version : Network Advantage
- Fan Module Options : 2x C9200-FAN Fan Modules Included
- Power Supplies Included : 1x PWR-C5-600WAC Power Supplies Included - 2x Slots - 2nd Power Supply ordered separately
- Power Supply Options : PWR-C5-125WAC, PWR-C5-600WAC, PWR-C5-1KWAC, PWR-C5-BLANK
- PoE Budget : 370W (with 1x PSU), 740W (with 2x PSU)
- Switching Capacity : 128 Gbps (288 Gbps with Stacking)
- Forwarding Rate : 190.4 Mpps (214 Mpps with Stacking)
- MAC Address Table Size : 32,000
- SD Access Support : Yes (4 Virtual Networks)
- Model Number : C9200-24P-A
- Part Number : C9200-24P-A, C9200-24P-A=, C9200-24P-A-WS
- Condition : New
- One (1) NEW Cisco C9200-24P-A 24x 1GB PoE+ RJ45 1x Module Slot Switch as described above
