The NEW Cisco C9300-24P-A switch offers 24x 1GB PoE+ RJ45 ports with a maximum PoE budget of 445W (720W with optional second PSU). With a switching capacity of 208 Gbps (688 Gbps in stacking mode) and a forwarding rate of up to 154.76 Mpps (511.90 Mpps in stacking), this switch is designed for high-performance.
It features a MAC address table size of 32,000 and low latency suitable for demanding applications. The stack members can be connected to provide increased scalability, supporting up to eight switches stacked together seamlessly.
Cisco C9300-24P-A: Catalyst 9300 24x RJ45 PoE+ Ports.
- Network Ports : 24x 1 Gigabit Ethernet PoE+ RJ-45
- Product Family : Catalyst 9300 Series
- Management Ports : 1x RJ-45, 1x USB 2.0, 1x Mini USB
- Stacking Ports : 2x StackWise 480 Ports (480 Gbps Stacking Bandwidth), 2x StackPower Ports
- Stack Members : Up to eight switches can be connected in the stack | Supported stack members = Other C9300 SKUs with same license level - C9300 higher scale SKUs only stack with other like higher scale models
- Stacking Cable Options : STACK-T1-50CM, STACK-T1-1M, STACK-T1-3M, CAB-SPWR-30CM, CAB-SPWR-150CM - Cables sold separately
- Module Slots : 1x Expansion Module Slot - Modules are not included
- Module Options : C9300-NM-4G, C9300-NM-8X, C9300-NM-2Q, C9300-NM-4M, C9300-NM-2Y - Please note - Existing 3850 network modules are also supported in the Cisco Catalyst 9300 Series platforms.
- Switch Version : Network Advantage
- Fan Module Options : 3x FAN-T2 Field Replaceable Fan Modules Included
- Power Supplies Included : 1x PWR-C1-715WAC Power Supply included - 2x Slots
- Power Supply Options : PWR-C1-715WAC or PWR-C1-1100WAC
- PoE Budget : 445W (720W with 2nd PSU)
- Switching Capacity : 208 Gbps (688 Gbps with Stacking)
- Forwarding Rate : 154.76 Mpps (511.90 Mpps with Stacking)
- MAC Address Table Size : 32,000
- Model Number : C9300-24P-A
- Part Number : C9300-24P-A, C9300-24P-A=, C9300-24P-A-WS
- Condition : New
- One (1) NEW Cisco C9300-24P-A 24x 1GB PoE+ RJ45 1x Module Slot Switch Used as described above
