Juniper MPC5EQ-40G10G-IRB MX Series 6x 40GB QSFP+ Router Line Card

Juniper MPC5EQ-40G10G-IRB MX Series 6x 40GB QSFP+ Router Line Card

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: Seller refurbished
Pre-owned, tested by qualified techs, working, reset-to-factory default, grade A condition, and parts needed for normal functions are included (as described in the listing).
Warranty: 365 days
Warranty coverage period
SKU: NSH-8695

Overview

The Juniper MPC5EQ-40G10G-IRB line card for the MX Series supports 6 ports of 40GbE connectivity via QSFP+ modules. It delivers high-density networking capabilities designed to enhance throughput and scalability in carrier-grade setups.

Compatible with Junos OS, this module provides simplified routing configurations while supporting granular traffic management features like QoS classification and hierarchical queuing. The interface operates on an Inline Receive Buffer Type (IRB) architecture, ensuring improved low-latency packet processing across demanding tasks. Each port is capable of handling up to 200 Gbps per slot aggregate bandwidth for efficient data transmission at peak volumes without bottlenecks or delays.

Juniper MPC5EQ-40G10G-IRB: Fixed 6x 40GbE or 24x 10GbE GbE line card bundle with HQoS; supports 1 million queues and 128,000 sessions, includes full scale L2/L2.5, L3 features and up to 16 L3VPN instances.


Specifications

  • Network Ports : 6x 40 Gigabit Ethernet QSFP+ - or 24x 10 Gigabit Ethernet SFP+
  • VPN Support : full scale L2L2.5, L3 features, and up to 16 L3VPN instances
  • Line-rate throughput : up to 240 Gbps
  • Capacity : LAN-PHY mode - 10.3125 Gbps per-port, WAN-PHY mode - 9.95328 Gbps per-port
  • Features : full scale L2/L2.5, L3
  • Designed for : Juniper MX2000 Universal Routing Platform Series
  • Model Number : MPC5EQ-40G10G-IRB
  • Part Number : MPC5EQ-40G10G-IRB
  • Condition : Seller refurbished

Datasheet

More information on this Juniper MPC5EQ-40G10G-IRB.

Included

  • One (1) Seller Refurbished Juniper MPC5EQ-40G10G-IRB MX Series 6x 40GB QSFP+ Router Line Card as described above

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
  • Transceiver Modules Not Included
