NEW Cisco Meraki MS390-24U-HW 24x 1GB UPOE RJ45 1x Module Slot Unclaimed Switch
New

NEW Cisco Meraki MS390-24U-HW 24x 1GB UPOE RJ45 1x Module Slot Unclaimed Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-7015
UPC: 889728231404

Overview

The Cisco Meraki MS390-24U-HW is an advanced switch designed for high-performance network environments. With 24x 1GB UPOE RJ45 ports and a module slot, this plug-and-play switch provides flexible connectivity options.

Featuring a PoE budget of 830W, the MS390-24U-HW can power numerous devices simultaneously without compromising performance. It boasts an impressive switching capacity of up to 208 Gbps and a forwarding rate of 154.76 Mpps, ensuring seamless data flow even in bandwidth-intensive applications.

Equipped with a MAC address table size of up to 32,000 entries, this unclaimed switch offers efficient handling and routing capabilities across your network infrastructure.

Cisco Meraki MS390-24U-HW: 24x 1 Gigabit Ethernet RJ45 ports. This switch comes with an 1100WAC PSU. This switch also features 2 120G hardware stacking ports.


Specifications

  • Network Ports : 24x 1 Gigabit Ethernet UPoE RJ45
  • Management Ports : 1x RJ45 Management
  • Stacking Ports : 2x 120G Hardware Stack Port
  • Stacking Cable Options : Stacking Cables - MA-CBL-120G-50CM, MA-CBL-120G-1M, A-CBL-120G-3M, Stack Power Cables - MA-CBL-SPWR-30CM, MA-CBL-SPWR-150CM
  • Module Slots : 1x Uplink Module Slot - Module not included
  • Module Options : MA-MOD-2X40G (2x 40G Uplink Module), MA-MOD-4X10G (4x 10G Uplink Module), MA-MOD-8X10G (8x 10G Uplink Module)
  • Fan Module Options : 3x MA-FAN-16K2 Hot Swap Fans
  • Power Supplies Included : 1x MA-PWR-1100WAC PSU Included - 2x Slots - 2nd PSU ordered separately.
  • Power Supply Options : MA-PWR-350WAC, MA-PWR-715WAC, MA-PWR-1100WAC
  • PoE Budget : 830W
  • Switching Capacity : 208 Gbps
  • Forwarding Rate : 154.76 Mpps
  • MAC Address Table Size : 32,000
  • : Not Included - MA-RCKMNT
  • Model Number : MS390-24U-HW
  • Part Number : MS390-24U-HW, MS390-24U-HW=, MS390-24U-HW-WS
  • Condition : New


Included

  • One (1) NEW Cisco Meraki MS390-24U-HW 24x 1GB UPOE RJ45 1x Module Slot Unclaimed Switch as described above
