NEW Dell S4048-ON 48x 10GB SFP+ 6x 40GB QSFP+ Front-to-Back Air 210-ADUW Switch
New

NEW Dell S4048-ON 48x 10GB SFP+ 6x 40GB QSFP+ Front-to-Back Air 210-ADUW Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-1862
UPC: 011110530103

Overview

The Dell S4048-ON switch is a powerful and efficient networking solution. Its 48x 10GB SFP+ ports and 6x 40GB QSFP+ ports offer high-speed connectivity for data-intensive applications. The front-to-back airflow ensures optimal cooling in rack-mounted environments.

This switch has a capacity of up to 1.44Tbps (full-duplex), providing line-rate performance even under heavy loads with sub-650ns latency. Its forwarding rate of up to 1080 Mpps enables fast packet processing, ensuring smooth network traffic flow.

With a MAC address table size of up to 160,000 entries, this switch supports large-scale networks without compromising performance or stability.

Dell S4048-ON: S4048, 48x 10GbE SFP+, 6x QSFP+, 1x AC PSU, 2x Fans, Front-to-Back Airflow (I/O Panel to PSU Airflow - Normal Airflow).


Specifications

  • Network Ports : 48x 10 Gigabit Ethernet SFP+
  • Uplink Ports : 6x 40 Gigabit Ethernet QSFP+
  • Management Ports : 1x RJ45 console/management port with RS232 signaling, 1x USB 2.0 type A to support mass storage device, 1x Micro-USB 2.0 type B Serial Console Port
  • Stacking Ports : User port stacking support for up to six units and a total stack bandwidth of up to 320Gbps bandwidth
  • Firmware Version : OS 9
  • Fan Modules AirFlow Direction : 2x Fan Modules - Front-to-Back Airflow (I/O Panel to PSU Airflow - Normal Airflow)
  • Power Supplies Included : 1x AC PSU Included- Front-to-Back Airflow (I/O Panel to PSU Airflow - Normal Airflow)
  • Alternative Dell Part Numbers : J09D3 210-ADUW
  • Switching Capacity : 1.44Tbps (full-duplex) non-blocking switching fabric delivers line-rate performance under full load with sub 650ns latency
  • Forwarding Rate : 1080 Mpps
  • MAC Address Table Size : 160,000
  • Rack Mounts : Not Included - 770-BBGY Rail Kit can be ordered separately.
  • Model Number : S4048-ON
  • Part Number : S4048-ON, 450-AFNR, 210-ADUW, J09D3
  • Condition : New


Included

  • One (1) NEW Dell S4048-ON 48x 10GB SFP+ 6x 40GB QSFP+ Front-to-Back Air 210-ADUW Switch as described above
