NEW Dell Z9100-ON-RA EMC Z-Series 32x 100GB QSFP28 B-F Air (With OS10) Switch
New

NEW Dell Z9100-ON-RA EMC Z-Series 32x 100GB QSFP28 B-F Air (With OS10) Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-0189
UPC: 011110529664

Overview

Z9100-ON-RA Dell Switch - new: NetworkTigers offers this new Switch. This Dell Z9100-ON-RA Switch new in open box. We can overnight this Dell Z9100-ON-RA Switch to your site.

The Dell Z9100-ON is a member of the Dell EMC Z-Series of network switches and related products. These switches have a fixed configuration and are perfect for applications in high-performance environments.

The Dell Z9100-ON-RA EMC Z-Series is a high-performance, state-of-the-art networking switch for enterprise-level organizations. The Dell Z9100-ON-RA has impressive throughput capacity. It delivers an astounding 4400 Mpps forwarding rate (full duplex) with support for up to 32 ports at speeds up to 100G bE. This unit has a back-to-front or power supply to data port airflow. You want this airflow if your network cabling is in the "hot corridor" of your data center servers.

Dell Z9100-ON: 32x 100 Gigabit Ethernet QSFP28 switch with 6.4 Tbps switching capacity. Back-to-Front Airflow (PSU to I/O Panel Airflow - Reversed).


Specifications

  • Network Ports : 32x 100 Gigabit Ethernet QSFP28
  • Uplink Ports : 2x 10 Gigabit Ethernet SFP+
  • Management Ports : 1x RJ-45 Management with RS232 signalling, 1x USB 2.0 type A Storage
  • Firmware Version : Includes OS10
  • Fan Modules AirFlow Direction : 5x Fan Subsystems Included - Back-to-Front Airflow (PSU to I/O Panel Airflow - Reversed)
  • Power Supplies Included : 2x AC Power Supplies Included - Back-to-Front Airflow (PSU to I/O Panel Airflow - Reversed)
  • Alternative Dell Part Numbers : Z9100-ON-RA, Z9100-ON RA
  • Switching Capacity : 6.4 Tbps
  • Forwarding Rate : 4400 Mpps (Full Duplex)
  • MAC Address Table Size : 136,000
  • Latency : Sub 500ns
  • Rack Mounts : Not Included - Rack Mount Rail Kit is sold separately - 5RN1M / 770-BBGY
  • Model Number : Z9100-ON-RA
  • Part Number : Z9100-ON-RA, Z9100-ON RA
  • Condition : New


Included

  • One (1) NEW Dell Z9100-ON-RA EMC Z-Series 32x 100GB QSFP28 B-F Air (With OS10) Switch as described above
