The NVIDIA Mellanox MQM9700-NS2F is a 1U switch with 32 OSFP ports supporting up to 400 Gb/s per port. This back-to-front airflow model enables high-speed data transmission using InfiniBand HDR interfaces in data center environments.
Compatible with standard 19-inch racks, the MQM9700-NS2F uses AC power and supports rack-mount installations. It provides aggregate bandwidth of up to 12.8 Tb/s across its non-blocking architecture and is suitable for deployment in HPC clusters or enterprise storage networks requiring low latency switching at scale.
nVidia Mellanox MQM9700-NS2F: 64-ports 400Gb/s, 32 OSFP ports, managed, power-to-connector (P2C) airflow (forward).
- Network Ports : 32x 400 Gigabit Ethernet OSFP
- Management Ports : 1x USB 3.0 x1, 1x USB for I2C channel, 1x RJ45, 1x RJ45 (UART)
- Switch Version : MLNX-OS
- System Memory : Single 8GB, 2,666 mega transfers per second (MT/s), DDR4 SO-DIMM
- Storage : M.2 SSD SATA 16GB 2242 FF
- Fan Modules : 7x MTEF-FANF-L (6+1)
- Power Supplies : 2x MTEF-PSF-AC-K PSU's Included - 1+1 redundant and hot-swappable power
- Switching Capacity : 51.2 Tbps
- Forwarding Rate : 66.5 Bpps
- nVidia SKU : 920-9B210-00FN-0M0
- Latency : Extremely Low Latency
- CPU : x86 Coffee Lake i3
- Model Number : MQM9700-NS2F
- Part Number : MQM9700-NS2F, 920-9B210-00FN-0M0
- Condition : New
- One (1) NEW nVidia Mellanox MQM9700-NS2F 32x 400GB OSFP Back-to-Front Airflow Switch as described above
