Nvidia Mellanox MSX6036G-2SFS 36x 40GB QSFP+ B-F Air (P2C) Switch

Nvidia Mellanox MSX6036G-2SFS 36x 40GB QSFP+ B-F Air (P2C) Switch

ASK FOR QUOTE
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: Seller refurbished
Pre-owned, tested by qualified techs, working, reset-to-factory default, grade A condition, and parts needed for normal functions are included (as described in the listing).
Warranty: 365 days
Warranty coverage period
SKU: NSH-6681

Overview

MSX6036G-2SFS nVidia Switch: NetworkTigers offers this Switch for sale. This nVidia MSX6036G-2SFS Switch we sell is tech tested and set to defaults. We can overnight this nVidia MSX6036G-2SFS Switch to your location.

The Mellanox MSX6036G-2SFS is a high performance network switch from Mellanox. Mellanox is a leading supplier of end-to-end Ethernet and InfiniBand intelligent interconnect solutions for cloud and enterprise data centers.

Mellanox MSX6036G-2SFS: SwitchX-2 based 36 QSFP ports, InfiniBand to 40GbE Ethernet gateway system with a non-blocking switching capacity of 4Tb/s. 2 Power Supplies, Standard depth, Managed, PSU side to connector side airflow, Rail Kit and RoHS-6.


Specifications

  • Network Ports : 36x 40 Gigabit Ethernet QSFP+
  • Management Ports : 1x RJ-45 Console, 2x Gigabit Ethernet Management, 1x USB slot
  • Module Slots and Options : None Included.
  • Firmware Version : InfiniBand
  • Power Supplies Included : 2x MSX60-PF AC Power Supply Included - Back-to-Front Airflow (P2C)
  • Switching Capacity : Up to 4Tb/s aggregate switching capacity
  • Latency : 400ns latency between InfiniBand and Ethernet
  • Rack Mounts : Included (1-RU)
  • Model Number : MSX6036G-2SFS
  • Part Number : MSX6036G-2SFS
  • Condition : Seller refurbished

Datasheet

More information on this nVidia MSX6036G-2SFS.

Included

  • One (1) Seller Refurbished Nvidia Mellanox MSX6036G-2SFS 36x 40GB QSFP+ B-F Air (P2C) Switch as described above
  • One (1) Power Cord Included
  • One (1) Set of Rack Mount Brackets Included
  • One (1) Set of Rack Mount Rails Included

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
  • Transceiver Modules Not Included
