NetworkTigers: Reliable, Quality-Tested Network Equipment
Supporting network managers with high quality switches, routers, PDUs, and firewalls since 1996
Extreme 5420F-48P-4XE by Extreme Networks is a high-density patch panel designed for data centers or network closets. This 1U form factor device offers 48x 1GB PoE RJ45 interfaces and includes four additional integrated 10GB SFP+ ports for higher-speed connectivity.
The switch supports dual power supplies, with one fixed internal massive AC PSU included in the base configuration. To add redundancy and ensure continuous operation, users can install an optional second XN-ACPWR-920W power supply unit. This feature-rich solution caters to demanding networking requirements while providing flexibility in terms of port count configurations and reliable power delivery options for critical operations.
Extreme 5420F-48P-4XE: 5420 Universal Switch with 48 x 10/100/1000BASE-T full/half duplex 802.3at 30W PoE ports, includes 4 x 1/10Gb SFP+ uplink ports, 2 x Stacking/SFP-DD ports, 1 internal fixed PSU, one unpopulated PSU slot, fixed fan module, Base version.
- Network Ports : 48x 1 Gigabit Ethernet PoE+ RJ45 (802.3at 30W per port)
- Uplink Ports : 4x 10 Gigabit Ethernet SFP+
- Management Ports : 1x RJ45 Serial Console, 1x Out of Band Management RJ45, 2x USB A, 1x USB Micro-B Console
- Stacking Ports : 2x Stacking/SFP-DD Ports
- MACsec : MACsec-capable
- Switch Version : Base
- Power Supplies Included : 1x Fixed Internal 860W AC PSU - 2nd PSU = XN-ACPWR-920W (not inc)
- PoE Budget : 740W (Single PSU) 1480W (Dual PSU)
- Switching Capacity : 256 Gbps
- Forwarding Rate : 190.5 Mpps
- MAC Address Table Size : 32,000
- VLANs : 4,094
- Model Number : 5420F-48P-4XE
- Part Number : 5420F-48P-4XE
- Condition : Seller refurbished
- One (1) Seller refurbished Extreme 5420F-48P-4XE 5420 Series 48x 1GB PoE RJ45 4x 10GB SFP+ Switch as described above
- One (1) Power Cord Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
