The Ruckus 901-R650-US00 is an indoor Wi-Fi 6 access point that supports the latest wireless standard, 802.11ax. Its advanced features, like MU-MIMO and a high-performance antenna array, provide reliable and fast connectivity for enterprise and home environments.
Operating on both the standard frequency bands of 2.4GHz and dual-band (5GHz), it offers greater flexibility in network planning while ensuring efficient data transmission with a maximum data rate of up to 2400 Mbps.
The R650's impressive performance can handle multiple simultaneous connections thanks to its innovative technology that allows four spatial streams per radio chain (4x4:4). This means smoother streaming experiences, faster downloads/uploads, improved latency-sensitive applications – making it ideal for bandwidth-intensive tasks such as video conferencing or online gaming.
Ruckus 901-R650-US00 R650 Indoor Wi-Fi 6 (802.11ax) 4x4:4 MU-MIMO WAP
- Wi-Fi Standard : Wi-Fi 6 (802.11ax)
- Managed By : SmartZone, ZoneDirector, Standalone, or Unleashed (also cloud-manageable)
- Suggested Use : Medium-density deployments like office buildings, K-12 classrooms, libraries, and retail venues
- Region : US
- Radios : 2x Radios - 1x 2.4GHz and 1x 5GHz, dual-concurrent
- Spatial Streams per Radio : 2 streams on 2.4GHz using 2x2 by 2, and 4 streams on 5GHz using 4x4 by 4, for 6 total combined
- Maximum Data Rate : 574 Mbps on 2.4GHz and 2400 Mbps on 5GHz, adding up to roughly 2974 Mbps aggregate
- Bluetooth / IoT Radios : Bluetooth and IoT Radios include onboard BLE and Zigbee, plus a pluggable IoT module for future expansion
- PoE Standard : 802.3af or 802.3at, with full functionality including USB and the second Ethernet port requiring PoE+ - Power Adapter not included
- DC Power Input : DC Power Input is supported through an optional 48V, 0.75A, 36W power supply, part number 902-1170-US00, not included in the box
- Uplink Ports : 1x 2.5 Gigabit RJ45, 1x 1 Gigabit RJ45
- Other Ports : 1x USB Type A
- Antenna Type : BeamFlex+ adaptive antennas with polarization diversity - Adaptive antenna that provides unique antenna patterns per band
- Mounting Options : 902-0120-0000 (Spare, Accessory Mounting Bracket), 902-0195-0000 (Flush frame ceiling mounting uses a T-bar ceiling mount kit) - neither included
- Mounts Included : Includes adjustable acoustic drop ceiling bracket
- Model Number : 901-R650-US00
- Part Number : 901-R650-US00
- Condition : Seller refurbished
- One (1) Seller Refurbished Ruckus 901-R650-US00 Wi-Fi 6 802.11ax Internal Antenna Indoor Wireless AP as described above
- One (1) Ceiling Bracket Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Power Adapter Not Included
