The NEW Cisco C9120AXE-B Catalyst 9120AX WAP is designed for high-performance wireless connectivity in demanding environments.
With Wi-Fi 6 technology, this access point supports data rates of up to four spatial streams and features MU-MIMO capabilities for improved efficiency on both the 2.4 GHz and 5.0 GHz bands.
Equipped with external antennas, the C9120AXE-B can be customized to suit your specific coverage needs. This model includes a generous amount of DRAM at 2048 MB, ensuring smooth operation even under heavy network loads.
NEW Cisco C9120AXE-B Catalyst 9120AX 802.11ax (Wi-Fi 6) 4x4 MU-MIMO Ext Ant WAP
- Wi-Fi Standard : 802.11ax Wi-Fi 6, also backward compatible with 802.11a/b/g/n/ac
- Managed By : Cisco Catalyst 9800 Series Wireless Controllers, Cisco 3500/5520/8540 Series Wireless Controllers, Cisco Virtual Wireless Controller
- Suggested Use : Indoor challenging environments needing external antenna flexibility, suited for high-density and large open-area deployments such as auditoriums, convention centers, libraries, cafeterias, arenas/stadiums
- Region : US (Region B)
- Radios : Flexible Radio Assignment with two radios, either 2.4 GHz plus 5 GHz mode, or Dual 5 GHz mode for increased capacity, plus integrated Bluetooth Low Energy 5 radio
- Spatial Streams per Radio : 4x4 MIMO with four spatial streams on both radios
- Maximum Data Rate : Up to 5.38 Gbps PHY data rate 160 MHz on 5 GHz plus 20 MHz on 2.4 GHz, up to 5.2 Gbps over-the-air in Dual 5 GHz mode 2 x 2.6 Gbps
- Bluetooth / IoT Radios : Integrated Bluetooth Low Energy 5 radio for location tracking and wayfinding
- PoE Standard : 802.3at PoE+, 802.3bt Cisco UPOE/UPOE+, 802.3af PoE also supported with reduced functionality - PoE Injector sold separately
- Uplink Ports : 1x Multigigabit Ethernet port 100/1000/2500 RJ-45, IEEE 802.3bz, Auto-MDIX support
- Other Ports : Management console port RJ-45, USB 2.0 at 4.5W
- Antenna Type : External, sold separately, certified for antenna gains up to 6 dBi at 2.4 GHz and 5 GHz
- Antenna Options : Broad selection of external antennas available separately, smart antenna connector allows two sets of antennas active simultaneously on a single AP
- Mounts Included : Mounting Hardware is not included
- Model Number : C9120AXI-B
- Part Number : C9120AXE-B
- Condition : New
- One (1) NEW Cisco C9120AXE-B Wi-Fi 6 802.11ax Region B External Antenna Indoor WAP as described above
