The Cisco Catalyst 9200 switch, model C9200-24T-A, offers high-performance connectivity for your network needs. With its 24x 1GB RJ45 ports and an expansion module slot, this switch allows you to scale up your network as needed easily.
With a switching capacity of 128 Gbps (or even higher at 288 Gbps with stacking), the C9200-24T-A ensures fast and reliable data transfer within your network. It features a forwarding rate of 190.4 Mpps (up to 214 Mpps with stacking), enabling efficient packet processing.
This Cisco Catalyst also boasts a large MAC address table size of 32,000 entries that aids in seamless communication between devices on your network.
Cisco C9200-24T-A Catalyst 9200 24x 1GB RJ45 1x Expansion Module Slot Switch
- Network Ports : 24x 1 Gigabit Ethernet RJ45
- SMARTnet : If you are planning to put this under SMARTnet, please ask before purchasing. We cannot guarantee that the unit will be SMARTnet eligible unless checked prior to purchase.
- Management Ports : 1x RJ45 Console, 1x Gigabit Management, 2x USB, 1x Mini USB
- Stacking Ports : StackWise-160 possible through the use of C9200-STACK-KIT - Ordered Separately
- Stacking Options : Stacking Bandwidth = 160 Gbps | This switch cannot be stacked with fixed C9200 models or other Catalyst switches
- Stacking Cable Options : STACK-T4-50CM, STACK-T4-1M, STACK T4-3M - Not Included
- Module Slots : 1x Expansion Module Slot - Module not Included
- Module Options : C9200-NM-4G (4x 1GB SFP) , C9200-NM-4X (4x 1G/10G SFP), C9200-NM-BLANK - None Included - Ordered Separately
- Switch Version : Network Advantage
- AirFlow Direction : Front-to-Back Airflow (Standard)
- Fan Module Options : 2x C9200-FAN Fan Modules Included
- Power Supplies Included : 1x PWR-C6-125WAC Included - 2x Slots - 2nd Power Supply ordered separately
- Power Supply Options : PWR-C6-125WAC, PWR-C5-BLANK
- PoE Budget : N/A
- Switching Capacity : 128 Gbps (288 Gbps with Stacking)
- Forwarding Rate : 190.4 Mpps (214 Mpps with Stacking)
- MAC Address Table Size : 32,000
- VLAN ID's : 4096
- SD Access Support : Yes (4 Virtual Networks)
- Model Number : C9200-24T-A
- Part Number : C9200-24T-A, C9200-24T-A =, C9200-24T-A -WS
- Condition : Seller refurbished
- One (1) Seller Refurbished Cisco C9200-24T-A Catalyst 9200 24x 1GB RJ45 1x Expansion Module Slot Switch as described above
- One (1) Power Cord Included
- One (1) AC Power Supply Included
- Two (2) Fan Modules Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
- Network Modules Not Included
