NEW Cisco C9300-24U-E Catalyst 9300 24x 1GB UPoE RJ-45 1x Module Slot Switch
New

NEW Cisco C9300-24U-E Catalyst 9300 24x 1GB UPoE RJ-45 1x Module Slot Switch

$ 3,392.99
$ 2,875.99
Only 1 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-1824
UPC: 889728035798

Overview

The Cisco C9300-24U-E Catalyst 9300 switch offers 24 UPoE RJ-45 ports and a module slot for added flexibility. With a PoE budget of up to 830W (expandable with additional PSUs), this switch can power high-power devices efficiently.

This switch comes with one module slot, allowing you to add additional modules as needed. Its PoE budget of up to 830W ensures sufficient power supply for all connected devices.

With a switching capacity of 208 Gbps (688 Gbps with stacking) and a forwarding rate of up to 154.76 Mpps (511.90 Mpps with stacking), this switch offers seamless data transmission without any bottlenecks or delays.

The MAC Address Table size accommodates up to 32,000 entries, ensuring efficient handling of large-scale networks. Regarding latency, stack members allow for efficient connection of up to eight switches.

Cisco C9300-24U-E: Catalyst 9300 24x 1Gb RJ45 UPOE (Universal Power over Ethernet) ports.


Specifications

  • Network Ports : 24x 1 Gigabit Ethernet UPOE RJ-45
  • Management Ports : 1x Management Console RJ-45, 1x Management Console RJ-45, 1x USB 3.0 SSD
  • Stacking Ports : 2x StackWise 480 Ports (480 Gbps Stacking Bandwidth), 2x StackPower Ports - Cables sold separately - Cable Options are STACK-T1-50CM, STACK-T1-1M, STACK-T1-3M, CAB-SPWR-30CM, CAB-SPWR-150CM
  • Module Slots and Options : 1x Expansion Module Slot - Modules are not included
  • Expansion Module Options : C9300-NM-4G, C9300-NM-8X, C9300-NM-2Q - sold separately.
  • Fan Modules AirFlow Direction : 3x FAN-T2 Fan Modules Included
  • Power Supplies Included : 1x PWR-C1-1100WAC 1100W AC PSU Included - 2x PSU Slots - 2nd PSU ordered separately - Options for 2nd PSU are PWR-C1-1100WAC, PWR-C1-715WAC, PWR-C1-350WAC
  • PoE Budget : 830W (1180W with 350W 2nd PSU, 1440W with 715W 2nd PSU, 1440W with 1100W 2nd PSU)
  • Switching Capacity : 208 Gbps (688 Gbps with Stacking)
  • Forwarding Rate : 154.76 Mpps (511.90 Mpps with Stacking)
  • MAC Address Table Size : 32,000
  • Rack Mounts : Included (1-RU)
  • Stack Members : Up to eight switches can be connected in the stack | Supported stack members = Other C9300 SKUs with same license level - C9300 higher scale SKUs only stack with other like higher scale models
  • Model Number : C9300-24U-E
  • Part Number : C9300-24U-E, C9300-24U-E=, C9300-24U-E-WS
  • Condition : New


Included

  • One (1) NEW Cisco C9300-24U-E Catalyst 9300 24x 1GB UPoE RJ-45 1x Module Slot Switch as described above
