The Cisco C9300-24UB-A Catalyst 9300 switch is a powerful solution for network connectivity. With its 24 Ethernet ports supporting UPoE and RJ45 connections, this switch offers high-speed data transfer speeds across your network.
Featuring a module slot, the C9300-24UB-A allows you to expand your capabilities by adding additional modules. It has an impressive PoE budget of up to 830W (or even higher with optional second power supply units), providing ample power for devices such as IP phones or wireless access points.
With a switching capacity of 208 Gbps (which increases further when stacked together), this Cisco switch ensures quick and efficient data transmission throughout your network. Its forwarding rate reaches up to 154.76 Mpps (up to over five times that with stacking).
It boasts a MAC Address Table Size accommodating up to approximately 32k addresses.
Cisco C9300-24UB-A: Catalyst 9300 24x 1Gb RJ45 UPOE ports, Network Advantage.
- Network Ports : 24x 1 Gigabit Ethernet UPoE+ RJ45
- Management Ports : 1x RJ45, 1x USB 2.0, 1x Mini USB
- Stacking Ports : 2x StackWise 480 Ports (480 Gbps Stacking Bandwidth), 2x StackPower Ports - Cables sold separately
- Stack Members : Up to eight switches can be connected in the stack | Supported stack members = Other C9300 SKUs with same license level - C9300 higher scale SKUs only stack with other like higher scale models
- Stacking Cable Options : STACK-T1-50CM, STACK-T1-1M, STACK-T1-3M, CAB-SPWR-30CM, CAB-SPWR-150CM - Not Included
- Module Slots : 1x Expansion Module Slot - None included.
- Module Options : C9300-NM-4G, C9300-NM-8X, C9300-NM-2Q, C9300-NM-4M, C9300-NM-2Y - Please note - Existing 3850 network modules are also supported in the Cisco Catalyst 9300 Series platforms.
- Switch Version : Network Advantage
- Fan Module Options : 3x FAN-T2 Fan Modules Included
- Power Supplies Included : 1x PWR-C1-1100WAC 1100W AC PSU Included - 2x PSU Slots - 2nd PSU ordered separately
- Power Supply Options : PWR-C1-1100WAC, PWR-C1-715WAC, PWR-C1-350WAC - Not Included
- PoE Budget : 830W (1180W with 350W 2nd PSU, 1440W with 715W 2nd PSU, 1440W with 1100W 2nd PSU)
- Switching Capacity : 208 Gbps (688 Gbps with Stacking)
- Forwarding Rate : 154.76 Mpps (511.90 Mpps with Stacking)
- MAC Address Table Size : 32,000
- Model Number : C9300-24UB-A
- Part Number : C9300-24UB-A, C9300-24UB-A=, C9300-24UB-A-WS
- Condition : New
- One (1) NEW Cisco C9300-24UB-A Catalyst 9300 24x 1GB UPoE RJ45 1x Module Slot Switch as described above
