Cisco C9300L-24UXG-4X-E 24x 1GB UPoE RJ45 (8x MultiGB) 4x 10GB SFP+ Switch

Cisco C9300L-24UXG-4X-E 24x 1GB UPoE RJ45 (8x MultiGB) 4x 10GB SFP+ Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: Seller refurbished
Pre-owned, tested by qualified techs, working, reset-to-factory default, grade A condition, and parts needed for normal functions are included (as described in the listing).
Warranty: 365 days
Warranty coverage period
SKU: NSH-9746
UPC: 889728174091

Overview

The Cisco C9300L-24UXG-4X-E switch is a high-performance device offering 24 UPoE RJ45 ports, supporting up to 8 MultiGB Ethernet connections. With its PoE budget of 880W, it can provide power to various network devices, such as IP phones and wireless access points.

This switch also features four 10GB SFP+ ports for high-speed connectivity and flexibility in networking environments. Its switching capacity of 272 Gbps (or even higher when stacked) allows for efficient data transfer throughout the network.

With a forwarding rate of approximately two hundred million packets per second, this switch ensures smooth and uninterrupted performance in handling large traffic. The MAC address table size reaches up to thirty-two thousand entries, accommodating numerous connected devices on the network.

Cisco C9300L-24UXG-4X-E 24x 1GB UPoE RJ45 (8x MultiGB) 4x 10GB SFP+ Switch


Specifications

  • Network Ports : 16x 1 Gigabit Ethernet UPOE RJ45, 8x MultiGigabit RJ45 (100M/1G/2.5G/5G/10G)
  • Uplink Ports : 4x 10 Gigabit Ethernet SFP+
  • Management Ports : 2x USB, 1x Mini USB
  • Stack Technology : StackWise-320 (Optional Stacking Hardware - C9300L-STACK-KIT - ordered separately)
  • Supported Stack Members : Other C9300L SKUs with same license level (Number of Members - 8)
  • Switch Version : Network Essentials
  • Fan Module Options : 3x FAN-T2 Modules Included
  • Power Supplies Included : 1x PWR-C1-1100WAC-P Included - 2nd Power Supply ordered separately.
  • PoE Budget : 880W
  • Switching Capacity : 272 Gbps (Switching Capacity with Stacking - 592 Gbps )
  • Forwarding Rate : 202.38 Mpps
  • MAC Address Table Size : 32,000
  • Model Number : C9300L-24UXG-4X-E
  • Part Number : C9300L-24UXG-4X-E, C9300L-24UXG-4X-E=, C9300L-24UXG-4X-E-WS
  • Condition : Seller refurbished


Included

  • One (1) Seller Refurbished Cisco C9300L-24UXG-4X-E 24x 1GB UPoE RJ45 (8x MultiGB) 4x 10GB SFP+ Switch as described above
  • One (1) Power Cord Included
  • One (1) AC Power Supply Included
  • Three (3) Fan Modules Included
  • One (1) Set of Rack Mount Brackets Included

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
  • Transceiver Modules Not Included
