NEW HPE J9574A 3800-48G-PoE+-4SFP+ 48x 1GB PoE+ RJ-45 4x 10GB SFP+ Switch

NEW HPE J9574A 3800-48G-PoE+-4SFP+ 48x 1GB PoE+ RJ-45 4x 10GB SFP+ Switch

$ 3,449.99
Only 1 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-5250
UPC: 886112028237

Overview

The HPE J9574A 3800-48G-PoE+-4SFP+ switch is a high-performance networking solution with advanced features. With its PoE capability, it can power up to 48 devices using Ethernet cables, eliminating the need for separate power sources.

Equipped with 48x 1GB PoE+ RJ-45 ports and 4x 10GB SFP+ uplink interfaces, this switch offers flexible connectivity options. It has a switching capacity of 176 Gbps and supports forwarding rates of up to130.9 Mpps (million packets per second), ensuring seamless data transmission across your network.

With a MAC address table size of 65500 addresses,the J9574A can support large-scale networks without compromising performance. As for latency,it guarantees fast packet delivery with less than2.8 microseconds delay on average.

HPE J9574A: 48 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only + 4 fixed 1000/10000 SFP+ ports + 1 RJ-45 serial console port + 1 RJ-45 out-of-band management port + 1 stacking module slot. Included accessories: 1 HPE 3800 Switch Fan Tray (J9582A) + 1 HPE X312 1000W 100-240VAC to 54VDC Power Supply (J9580A).


Specifications

  • Network Ports : 48x 1 Gigabit Ethernet PoE+ RJ-45
  • Uplink Ports : 4x 10 Gigabit Ethernet SFP+
  • Management Ports : 1x Console RJ-45, 1x Gigabit Ethernet,
  • Stacking Ports : 1x Stacking Module Slot - module not included
  • Fan Modules AirFlow Direction : 1x J9582A HP E3800 Switch Fan Tray
  • Power Supplies Included : 1x J9580A HPE X312 1000-W Power Supply
  • PoE Budget : 1080W
  • Switching Capacity : 176 Gbps
  • Forwarding Rate : 130.9 Mpps
  • MAC Address Table Size : 65500
  • Latency : < 2.8 ┬Ás (LIFO 64-byte packets) (1000Mb)
  • Rack Mounts : Included (1-RU)
  • Model Number : J9574A
  • Part Number : J9574A, 3800-48G-PoE+-4SFP+
  • Condition : New


Included

  • One (1) NEW HPE J9574A 3800-48G-PoE+-4SFP+ 48x 1GB PoE+ RJ-45 4x 10GB SFP+ Switch as described above
