NEW HPE Aruba JL659A CX 6300 Series 48x 5GB PoE RJ-45 4x 50GB SFP56 Switch
New

NEW HPE Aruba JL659A CX 6300 Series 48x 5GB PoE RJ-45 4x 50GB SFP56 Switch

$ 5,481.99
$ 4,969.99
8 in stock
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-9647
UPC: 190017339405

Overview

The HPE Aruba JL659A CX 6300 Series is a powerful switch designed with advanced features to meet the demands of modern networks. It provides high-speed connectivity for various devices with 48x 5GB PoE RJ-45 ports and 4x25GB SFP56 ports.

One standout feature is its impressive switching capacity of up to 880 Gbps, which ensures smooth data transmission across all connected devices. The forwarding rate of 654 Mpps allows for rapid packet processing without slowing down network performance.

With a large MAC Address Table Size of 32,768 entries, this switch can handle extensive networking setups effortlessly. The latency has been minimized to ensure swift response times during high-bandwidth tasks.

Aruba JL659A: 6300M 48-port HPE Smart Rate 1/2.5/5GbE Class 6x PoE and 4-port SFP56 Switch.


Specifications

  • Network Ports : 48x 5 Gigabit Ethernet PoE RJ-45
  • Uplink Ports : 4x 1/10/25/50 Gigabit Ethernet SFP56 (Also used as stacking ports)
  • Management Ports : 1x USB-C Console Port, 1x OOBM, 1x USB Type A Host, 1x Bluetooth dongle to be used with CX Mobile App
  • Stacking Ports : SFP56 Uplink ports are used for stacking - They support speeds of 1GB, 10GB, and 25GB for a total of up to 200 Gbps of stacking throughput per switch
  • Stacking Options : Support for up to 10 switches (or members) in a stack via chain or ring topology
  • Stacking Cable Options : 10GB = J9281D, J9283D | 25GB = JL487A, JL488A, JL489A | 50GB = R0M46A, R0M47A
  • AirFlow Direction : Front-to-Back Airflow
  • Fan Module Options : 2x Fan Tray Slots - 2x Fan Tray Included
  • Power Supplies Included : 2x PSU Slots - 1x Min Required - Ordered Separately - Options are JL086A, JL087A, JL670A
  • Power Supply Options : JL086A (680W AC), JL087A (1050W AC), JL670A (1600W AC)
  • PoE Budget : 2880W
  • Switching Capacity : 880 Gbps
  • Forwarding Rate : 654 Mpps
  • MAC Address Table Size : 32,768
  • 1Gbps : = 2.28μSec, 10Gbps = 1.46μSec, 25Gbps = 1.90μSec, 50Gbps = 3.49μSec
  • DRAM and Flash : 8GB DDR4, 32GB eMMC
  • Model Number : JL659A
  • Part Number : JL659A, JL659A#ABA
  • Condition : New


Included

  • One (1) NEW HPE Aruba JL659A CX 6300 Series 48x 5GB PoE RJ-45 4x 25GB SFP56 Switch as described above
