NEW HPE Aruba JL728B 48x 1GB Class 4 PoE RJ-45 4x 10GB SFP+ Switch
New

NEW HPE Aruba JL728B 48x 1GB Class 4 PoE RJ-45 4x 10GB SFP+ Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-0962

Overview

The HPE Aruba JL728B Switch by Hewlett Packard Enterprise is a fixed-form-factor unit with forty-eight 10/100/1000BASE-T Class 4 PoE RJ‑45 ports and four 10 GbE SFP+ uplink interfaces. It provides up to 176 Gbps switching capacity and supports forwarding rates of up to 130.9 Mpps.

This switch uses a quad-core ARM Cortex‑A72 processor operating at 1.8 GHz, supporting low-latency data transmission—approximately 2.28 μs for gigabit links and 1.46 μs for ten-gigabit paths—and maintains a MAC address table accommodating up to 32,768 entries. The model supplies IEEE802.3af/at-compliant Power over Ethernet from its access ports while allowing fiber aggregation through the SFP+ slots for higher-bandwidth uplinks or stacking purposes./p>

HPE Aruba Networking CX 6200F 48G Class 4 PoE 4SFP+ 740W Switch.


Specifications

  • Network Ports : 48x 1 Gigabit Ethernet PoE+ RJ-45 (Class 4 PoE) - Supports PoE Standards IEEE 802.3af, 802.3a
  • Uplink Ports : 4x 10 Gigabit Ethernet SFP+
  • Management Ports : 1x USB-C Console Port, 1x OOBM, 1x USB Type-A Host port, 1x RJ-45 Console Port
  • Stack Size : 8 members (with other 24/48p 6200F and 6200M switches only) - Stacking Bandwidth = 40Gbps
  • CPU : Quad Core ARM Cortex A72 @ 1.8 GHz
  • Packet Buffer : 8 MB Packet Buffer Memory
  • Fan Module Options : Fixed
  • Power Supplies Included : Fixed Internal
  • PoE Budget : Up to 740W of Class 4 PoE Power
  • Switching Capacity : 176 Gbps
  • Forwarding Rate : Up to 130.9Mpps
  • MAC Address Table Size : 32,768
  • Latency : 1 Gbps = 2.28 μSec, 10 Gbps = 1.46 μSec
  • DRAM and Flash : 8 GB DDR4 16 GB eMMC
  • Model Number : JL728B
  • Part Number : JL728B
  • Condition : New


Included

  • One (1) NEW HPE Aruba JL728B 48x 1GB Class 4 PoE RJ-45 4x 10GB SFP+ Switch as described above
