NEW HPE Aruba JW172A AP-224 Dual Radio 802.11ac 3x3:3 MIMO External Antenna WAP
New

NEW HPE Aruba JW172A AP-224 Dual Radio 802.11ac 3x3:3 MIMO External Antenna WAP

$ 166.99
$ 139.99
Only 2 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-5236
UPC: 190017020730

Overview

The HPE Aruba JW172A AP-224 is a dual radio 802.11ac access point with external antennas, offering a maximum gain of 1.5 dB in the 2.4 GHz frequency and 3.0 dB in the 5 GHz frequency bands for improved coverage and throughput capabilities up to 1Gbps data rate.

Designed specifically for high-performance wireless networking needs, this product features MIMO technology that enhances signal strength and reduces interference, ensuring reliable connectivity in both indoor and outdoor environments.

With advanced antenna options providing optimal coverage across multiple frequencies, businesses can trust in the robust design of the HPE Aruba JW172A AP-224 to deliver consistent performance without compromising on quality or reliability when deploying their network infrastructure solutions.

Aruba JW172A: AP-224 802.11n/ac Dual 3x3:3 Radio Antenna Connectors Wireless AP.


Specifications

  • Interface Ports : 2x 1 Gigabit Ethernet PoE RJ45
  • Radios : 2.4-GHz (600 Mbps max) and 5-GHz (1.3 Gbps max) radios, each with 3x3 MIMO and three combined, diplexed external antenna connectors
  • Management Ports : 1x RJ45 Console, 1x USB 2.0 (Type A)
  • Antenna Ports : 3x RP-SMA Connectors for External Dual-Band Antennas - Antennas not included
  • Max Gain : 1.5 dB in 2.4 GHz and 3.0 dB in 5 GHz
  • Power Options : Power over Ethernet (PoE) - 48 Vdc (nominal) 802.3af or 802.3at Compliant source | Direct DC source - 12 Vdc nominal, +/- 5% - JX989A AC-DC Adapter Kit is Not Included (sold separately) - JW629A Injector sold separately
  • Frequency : 2.4 GHz, 5GHz
  • MIMO : 3x3 MIMO
  • Maximum Data Rate : 1.3 Gbps
  • Mounts : Included - 2x for attaching to 9/16-inch or 15/16-inch T-bar drop-tile ceiling (JW044A)
  • Model Number : JW172A
  • Part Number : JW172A, AP-224
  • Condition : New


Included

  • One (1) NEW HPE Aruba JW172A AP-224 Dual Radio 802.11ac 3x3:3 MIMO External Antenna WAP as described above
