NEW Cisco N9K-C93180YC-FX3 48x 25GB SFP28 6x 100GB QSFP28 F-B Air Switch
New

NEW Cisco N9K-C93180YC-FX3 48x 25GB SFP28 6x 100GB QSFP28 F-B Air Switch

$ 9,775.99
$ 7,475.99
Only 2 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-0606
UPC: 889728175692

Overview

The NEW Cisco N9K-C93180YC-FX3 is a high-capacity switch that delivers up to 3.6 Tbps switching capacity and forwards data at rates of 1.2 Bpps, designed for modern network requirements.

It features 48 ports supporting SFP28 with speeds up to 25 GbE and six QSFP28 uplink ports enabling connectivity at 40/100 GbE options, providing flexible scaling capabilities. The device supports a MAC address table size of up to 512,000 entries for complex systems requiring extensive scalability in Layer-2 configurations.

NEW Cisco N9K-C93180YC-FX3 48x 25GB SFP28 6x 100GB QSFP28 F-B Air Switch


Specifications

  • Network Ports : 48x 25 Gigabit Ethernet SFP28
  • Uplink Ports : 6x 100 Gigabit Ethernet QSFP28
  • Management Ports : 1x RJ45 Management, 1x USB, 1x RS-232 Serial
  • Switch Version : Cisco NX-OS
  • AirFlow Direction : Port Side Intake (Front-to-Back Airflow)
  • Fan Module Options : 4x NXA-FAN-35CFM-PI Fan Modules Included - Port Side Intake (Front-to-Back Airflow)
  • Power Supplies Included : 1x NXA-PAC-650W-PI PSU Included (N+1 Redundancy) - 2x Slots - 2nd PSU ordered separately
  • Power Supply Options : NXA-PAC-650W-PE is the alternative airflow PSU option (B-F)
  • Switching Capacity : 3.6 Tbps
  • Forwarding Rate : 1.2 Bpps
  • MAC Address Table Size : 512,000
  • Model Number : N9K-C93180YC-FX3
  • Part Number : N9K-C93180YC-FX3
  • Condition : New


Included

  • One (1) NEW Cisco N9K-C93180YC-FX3 48x 25GB SFP28 6x 100GB QSFP28 F-B Air Switch as described above
