The NEW Cisco N9K-C9396TX switch delivers a fixed-port configuration with 48x 10GBASE-T ports and 8x QSFP+ uplinks, designed to support high-speed data center deployments. It provides up to 480 Gbps of switching capacity and supports forwarding at rates reaching 1.92 Tbps.
Equipped with front-to-back airflow for thermal efficiency, this model suits spaces requiring specific cooling demands. The included N9K-M12PQ module adds flexibility by incorporating additional port configurations while supporting MAC address table sizes of up to 96,000 entries—essential for large-scale connectivity needs.
Optional modules such as the N9K-M4PC-CFP2 or other M-line series expand compatibility further but are not pre-installed in this unit.
NEW Cisco N9K-C9396TX 48x 10GB Copper 8x 40GB QSFP+ Front-to-Back Airflow Switch
- Network Ports : 48x 10 Gigabit Ethernet RJ45
- Uplink Ports : See "Module Slots and Options"
- Management Ports : 2x USB, 1x Management (Gigabit LAN) RJ45, 1x Serial RS-232 RJ45
- Module Slots : 1x N9K-M12PQ Module Included - 8x 40 Gigabit Ethernet QSFP+
- Module Options : N9K-M6PQ-E, N9K-M6PQ, N9K-M12PQ, N9K-M4PC-CFP2 - Not Included
- AirFlow Direction : Front-to-Back Airflow (Port Side Intake / Reverse Airflow)
- Fan Module Options : 3x N9K-C9300-FAN2-F Fan Modules Included
- Power Supplies Included : 2x N9K-PAC-650W - 650W AC Power Supplies included
- Switching Capacity : 480 Gbps
- Forwarding Rate : 1.92 Tbps
- MAC Address Table Size : 96,000 (Maximum)
- Model Number : N9K-C9396TX
- Part Number : N9K-C9396TX, N9K-C9396TX=, N9K-C9396TX-WS
- Condition : New
- One (1) NEW Cisco N9K-C9396TX 48x 10GB Copper 8x 40GB QSFP+ Front-to-Back Airflow Switch as described above
