NEW Arista CCS-720XP-24Y6-2F 24x 1GB PoE RJ45 6x 25GB SFP+ F-B Air Switch
New

NEW Arista CCS-720XP-24Y6-2F 24x 1GB PoE RJ45 6x 25GB SFP+ F-B Air Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-6811

Overview

The NEW Arista CCS-720XP-24Y6-2F is a high-performance switch with 24x 1GB PoE RJ45 ports and 6x 25GB SFP+ F-B Air uplink ports. The switch features a PoE budget of up to 1853W, depending on the power supply configuration.

With switching capacity throughput of up to (348) Gbps and a forwarding rate of 259 Mpps, this switch offers excellent performance for demanding networking environments. It has a MAC address table size of at least 112,000 entries and an ultra-low latency rating of just 1.2 microseconds.

Designed for efficiency and reliability in data centers or enterprise networks requiring high bandwidth connectivity options like fiber-optic links using SFP+ transceivers, this Arista switch provides industry-leading capabilities without compromising quality or speed.

NEW Arista CCS-720XP-24Y6-2F 24x 1GB PoE RJ45 6x 25GB SFP+ F-B Air Switch


Specifications

  • Network Ports : 24x 1 Gigabit Ethernet PoE RJ45 (10/100M-1GB) - (30W 802.3af/at)
  • Uplink Ports : 6x 25 Gigabit Ethernet SFP+
  • Management Ports : 1x Console RJ45, 1x Gigabit Management RJ45, 1x USB
  • Product Family : 720XP Series
  • Switching Bandwidth : 400 Gbps
  • AirFlow Direction : Front-to-Back Airflow
  • Fan Module Options : 3x FAN-7000-F Fan Modules Included - Front to Back Airflow
  • Power Supplies Included : 2x Slots - 2x PWR-621-AC-RED 650W AC PSU's Included - Front-to-Back Airflow
  • Power Supply Options : Other PSU Options are PWR-1021-AC-RED (1050W AC), PWR-521-DC-RED (500W DC)
  • PoE Budget : 583W (w/ Default 650W AC PSU), 1113W (w/ Dual 650W AC PSU) - 1853W (w/ Dual 1050W AC PSU's), 860W (w/ Dual 500W DC PSU's)
  • Throughput (FDX) : 174 (348) Gbps
  • Forwarding Rate : 259 Mpps
  • MAC Address Table Size : 112,000
  • Latency : 1.2 microseconds
  • : Included (1RU)
  • Model Number : CCS-720XP-24Y6-2F
  • Part Number : CCS-720XP-24Y6-2F
  • Condition : New


Included

  • One (1) NEW Arista CCS-720XP-24Y6-2F 24x 1GB PoE RJ45 6x 25GB SFP+ F-B Air Switch as described above
