NEW Cisco C9300L-24UXG-2Q-A 24x 1GB UPoE RJ45 (8x MultiGB) 2x QSFP+ Switch
New

NEW Cisco C9300L-24UXG-2Q-A 24x 1GB UPoE RJ45 (8x MultiGB) 2x QSFP+ Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-6532
UPC: 889728174060

Overview

The NEW Cisco C9300L-24UXG-2Q-A is a powerful switch with high-performance networking capabilities. With 24 ports of UPoE RJ45 connectivity, it enables fast and reliable connections for your network devices. This switch has 8s MultiGB ports and 2 QSFP+ interfaces for high-speed uplink options.

This switch provides a PoE budget of 722W, making it suitable for powering multiple devices without additional power supplies, such as IP phones or wireless access points. It also boasts an impressive switching capacity of 352 Gbps (672 Gbps with stacking) to support bandwidth-intensive applications.

With a forwarding rate of up to 261.90 Mpps (500.00 Mpps with stacking), data can be transmitted quickly across your network, ensuring efficient communication between devices.

Its MAC address table size allows you to seamlessly accommodate large numbers of connected devices in your network environment.

NEW Cisco C9300L-24UXG-2Q-A 24x 1GB UPoE RJ45 (8x MultiGB) 2x QSFP+ Switch


Specifications

  • Network Ports : 16x 1 Gigabit Ethernet UPOE RJ45, 8x MultiGigabit RJ45 (100M/1G/2.5G/5G/10G)
  • Uplink Ports : 4x 40 Gigabit Ethernet QSFP+
  • Management Ports : 2x USB, 1x Mini USB
  • Stack Technology : StackWise-320 (Optional Stacking Hardware - C9300L-STACK-KIT - ordered separately)
  • Supported Stack Members : Other C9300L SKUs with same license level (Number of Members - 8)
  • Firmware Version : Network Advantage
  • Fan Modules AirFlow Direction : 3x FAN-T2 Modules Included
  • Power Supplies Included : 1x PWR-C1-1100WAC-P Included - 2nd Power Supply ordered separately.
  • PoE Budget : 722W
  • Switching Capacity : 352 Gbps (Switching Capacity with Stacking - 672 Gbps)
  • Forwarding Rate : 261.90 Mpps (Forwarding Rate with Stacking - 500.00 Mpps)
  • MAC Address Table Size : 32,000
  • Rack Mounts : Included (1-RU)
  • Model Number : C9300L-24UXG-2Q-A
  • Part Number : C9300L-24UXG-2Q-A, C9300L-24UXG-2Q-A=, C9300L-24UXG-2Q-A-WS
  • Condition : New


Included

  • One (1) NEW Cisco C9300L-24UXG-2Q-A 24x 1GB UPoE RJ45 (8x MultiGB) 2x QSFP+ Switch as described above
