NEW Cisco Meraki MS390-48UX-HW 48x MultiGB UPoE RJ45 1x Slot Unclaimed Switch
New

NEW Cisco Meraki MS390-48UX-HW 48x MultiGB UPoE RJ45 1x Slot Unclaimed Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-4273
UPC: 889728231459

Overview

The Cisco Meraki MS390-48UX-HW is a powerful and versatile switching solution for modern network environments. Its 48 multiGB UPoE RJ45 ports provide high-speed connectivity for various devices.

This switch offers an impressive PoE budget of 490W, ensuring sufficient power delivery to connected equipment. It boasts a superior capacity of 580 Gbps for seamless data transmission across the network. The forwarding rate is an exceptional 431.54 Mpps, enabling fast and reliable performance.

Featuring a MAC Address Table Size of up to 32,000 entries, this switch efficiently manages network traffic. The one available slot allows flexibility in expanding your networking capabilities further.

Cisco Meraki MS390-48UX-HW: 36 2.5 Gigabit Ethernet RJ45 ports and 12 MultiGigabit Ethernet RJ45 UPOE ports. This switch comes with an 1100WAC PSU.


Specifications

  • Network Ports : 48x MultiGigabit Ethernet RJ-45 (36x 2.5 Gigabit Ethernet RJ-45, 12x MultiGigabit Ethernet UPoE RJ-45)
  • Management Ports : 1x RJ-45 Management
  • Stacking Ports : 2x 120G Hardware Stack Port
  • Stacking Cable Options : MA-CBL-120G-50CM, MA-CBL-120G-1M, MA-CBL-120G-3M, MA-CBL-SPWR-30CM, MA-CBL-SPWR-150CM
  • Module Slots : 1x Uplink Module Slot - Module is not included
  • Module Options : MA-MOD-2X40G (2 x 40G Uplink Module), MA-MOD-4X10G (4 x 10G Uplink Module), MA-MOD-8X10G (8 x 10G Uplink Module)
  • Fan Module Options : 3x MA-FAN-16K2 Hot Swap Fans
  • Power Supplies Included : 1x MA-PWR-1100WAC PSU Included - 2x Slots - 2nd PSU ordered separately.
  • Power Supply Options : MA-PWR-350WAC, MA-PWR-715WAC, MA-PWR-1100WAC
  • PoE Budget : 490W (Universal Power over Ethernet) - 60W per port. (Up to 8 of the 12 UPoE ports can be used at one time at 60W per port) - These ports offer both PoE+ and UPoE Support
  • Switching Capacity : 580 Gbps
  • Forwarding Rate : 431.54 Mpps
  • MAC Address Table Size : 32,000
  • : Included (1-RU) - MA-RCKMNT
  • Model Number : MS390-48UX-HW
  • Part Number : MS390-48UX-HW, MS390-48UX-HW=, MS390-48UX-HW-WS
  • Condition : New


Included

  • One (1) NEW Cisco Meraki MS390-48UX-HW 48x MultiGB UPoE RJ45 1x Slot Unclaimed Switch as described above
