NEW HPE Aruba AP-515 Q9H73A US TAA Wi-Fi 6 802.11ax Internal Antenna WAP

Ask for quote

Shipping: OVERNIGHT OPTION

Condition: New

Warranty: 365 days

SKU: NSN-1682

UPC: 190017273730

The NEW HPE Aruba Q9H73A AP-515 US is a dual-radio WiFi 6 access point that offers high performance and reliability. With support for the latest IEEE 802.11ax standard, this WAP provides faster speeds and increased capacity compared to previous generations of wireless technology.

It operates on both the 2.4 GHz and 5 GHz frequency bands, delivering maximum data rates of up to 575 Mbps (2.4 GHz) and 4.8 Gbps (5 GHz). The peak data rate for this access point is an impressive 5..4 Gbps, making it suitable for demanding network environments in the regulatory domain - US.

NEW HPE Aruba Q9H73A AP-515 US Dual Radio 802.11ax WiFi 6 MU-MIMO OFDMA TAA WAP

Wi-Fi Standard : 802.11ax (Wi-Fi 6), MU-MIMO, OFDMA
Managed By : Aruba Central / Aruba Mobility Controller
Suggested Use : Indoor, campus, high density environments
Region : United States (TAA)
Radios : Dual Radio, 5GHz 802.11ax 4x4 MIMO & 2.4GHz 802.11ax 2x2 MIMO, plus Bluetooth 5 and Zigbee (802.15.4) radio
Spatial Streams per Radio : 5GHz 4SS / 2.4GHz 2SS
Maximum Data Rate : 2.69 Gbps aggregate (574 Mbps 2.4GHz + 4.8 Gbps 5GHz max)
Bluetooth / IoT Radios : Bluetooth 5 and Zigbee (802.15.4)
PoE Standard : 802.3af (class 3) / 802.3at (class 4) / 802.3bt (class 5)
DC Power Input : 12V DC nominal ±5% (2.1/5.5mm center-positive jack)
Uplink Ports : 1x 100/1000/2500BASE-T SmartRate RJ-45 (E0 PoE) and 1x 10/100/1000BASE-T RJ-45 (E1)
Other Ports : 1x USB 2.0 Type-A
Antenna Type : Integrated dual-band downtilt omni-directional
Antenna Ports : N/A (integrated)
Antenna Options : N/A (integrated antennas, not removable)
Mounting Options : Ordered Separately - R3J15A (Type A, flat rail 9/16), R3J16A (Type B, flat rail 15/16), R3J17A (Type C, profile rail 9/16), R3J18A (Type D, solid surface), R3J19A (Type E, wall-box)
Mounts Included : A mounting bracket has been pre-installed on the back of the AP. This bracket is used to secure the AP to any of the (sold separately) mount kits
Model Number : Q9H73A
Part Number : Q9H73A, AP-515, AP-515-US, AP-515-US-TAA
Condition : New
