The Juniper QFX5120-48T-AFO is a 1U form factor switch manufactured by Juniper Networks. It features 48x 10G RJ45 interfaces and 6x 100GB QSFP28 F-B Airflow interfaces, with a switching capacity of up to 2.16 Tbps (bidirectional) and a MAC Address Table Size of up to 288,000 entries.
This high-performance switch is suitable for data center deployments requiring high-speed connectivity in both small and large-scale environments. With its generous port count and versatile interface options, the QFX5120-48T-AFO can meet the demands of modern networking applications while providing reliable performance. The unit's compact design allows for easy integration into existing network setups without compromising on functionality or efficiency.
Juniper QFX5120-48T-AFO: QFX5120-48T, 48x10GbE+6x100GbE, 1 U, AC airflow out.
- Network Ports : 48x 10 Gigabit Ethernet RJ45 (each port is dual speed supporting 1GbE/10GbE)
- Uplink Ports : 6x 100 Gigabit Ethernet QSFP28 (ports 50 and 51 can be configured as a 4 x 25GbE interface or as 100 Gbps interfaces)
- Management Ports : 1x RJ45 Management
- Virtual Chassis : Up to 2 members
- Switch Version : JUNOS OS
- AirFlow Direction : Front-to-Back Airflow
- Fan Module Options : 5x (Redundant 4+1) QFX5110-FANAFO Fan Modules Included
- Power Supplies Included : 2x JPSU-650W-AC-AO 650W AC PSU's Included
- Power Supply Options : QFX5110-FANAFI (Not Included)
- Switching Capacity : 1.08/2.16 Tbps (uni/bidirectional)
- Forwarding Rate : 1 Bpps
- MAC Address Table Size : 288,000
- VLAN's : 4094
- Model Number : QFX5120-48T-AFO
- Part Number : QFX5120-48T-AFO
- Condition : Seller refurbished
- One (1) Seller refurbished Juniper QFX5120-48T-AFO 48x 10G RJ45 6x 100GB QSFP28 F-B Airflow Switch as described above
- Two (2) Power Cords Included
- Two (2) AC Power Supplies Included
- Five (5) Fan Modules Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
- Rack Mount Rails Not Included
- Rack Mount Brackets Not Included
