Juniper QFX5130-32CD-AFO 400GB QSFP-DD Front-to-Back Airflow Switch

Juniper QFX5130-32CD-AFO 400GB QSFP-DD Front-to-Back Airflow Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: Seller refurbished
Pre-owned, tested by qualified techs, working, reset-to-factory default, grade A condition, and parts needed for normal functions are included (as described in the listing).
Warranty: 365 days
Warranty coverage period
SKU: NSB-7921

Overview

The Juniper QFX5130-32CD-AFO is a high-performance switch designed for data center networks. It offers 32 ports of 400GbE, providing fast and reliable connectivity for demanding applications. This switch features deep buffers to handle traffic fluctuations without dropping packets.

With support for advanced routing protocols such as BGP and OSPF, the QFX5130-32CD-AFO can easily integrate into existing network setups. Additionally, this switch provides enhanced security features like MACsec encryption to protect sensitive data in transit. Overall, the Juniper QFX5130-32CD-AFO is an excellent choice for organizations looking to upgrade their network infrastructure with a reliable and high-capacity solution.

Juniper QFX5130-32CD-AFO: QFX5130 (hardware only; software services sold separately), 32 QSFP-DD/QSFP+/QSFP28 ports, redundant fans, 2 AC power supplies, front-to-back airflow


Specifications

  • Network Ports : 32 400 Gigabit Ethernet QSFP-DD
  • Max Port Breakout : 64 x 200GbE + 2 x 10GbE or 128 x 100/50/25/10GbE + 2 x 10GbE or 32 x 40GbE + 2 x 10GbE
  • Switch Version : Junos OS Evolved
  • System Memory : 32GB (16GBx2) of DDR4
  • AirFlow Direction : Front-to-Back Airflow
  • Fan Modules : 6x QFX5130-48C-FANAO Fan Modules Included
  • Power Supplies : 2x JPSU-1600W-1UACAFIO1600W AC PSU's included
  • Switching Capacity : Up to 12.8/25.6 Tbps (uni/ bidirectional)
  • Forwarding Rate : 5.3 Bpps
  • MAC Address Table Size : 160,000
  • IPv4 Unicast Routes : 1.2M
  • IPv6 Unicast Routes : 850K
  • VLANs Supported : 4,000
  • Packet Buffer : 132 MB
  • CPU : Intel Broadwell DE
  • Model Number : QFX5130-32CD-AFO
  • Part Number : QFX5130-32CD-AFO
  • Condition : Seller refurbished

Datasheet

More information on this Juniper QFX5130-32CD-AFO.

Included

  • One (1) Seller refurbished Juniper QFX5130-32CD-AFO 400GB QSFP-DD Front-to-Back Airflow Switch as described above
  • Two (2) Power Cords Included
  • Two (2) AC Power Supplies Included
  • Six (6) Fan Modules Included

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
  • Transceiver Modules Not Included
  • Rack Mount Rails Not Included
  • Rack Mount Brackets Not Included
