The HPE Aruba S0M82A CX 6200F Series switch is a rack-mountable unit from Hewlett Packard Enterprise. It features 24x 1GbE RJ45 PoE+ ports and 4x 1GbE SFP uplink slots, supporting transmission speeds up to 128 Gbps in switching capacity.
This model supports Layer-2 Ethernet traffic with forwarding rates up to 95.2 Mpps and latency as low as 2.28μSec at 1Gbps links or 1.46μSec on higher-speed paths like stacked interfaces when applicable across compatible models within the same series using available module options for expansion where supported by system firmware versions . The MAC address table holds up to 32,768 entries , suitable for moderate port density implementations ; power-over-Ethernet output per port aligns with IEEE standards via standard AC input through rear connectors.
HPE Aruba S0M82A: HPE Aruba Networking CX 6200F 24G Class 4 PoE 4SFP 370W Switch.
- Network Ports : 24x 1 Gigabit Ethernet PoE+ RJ45
- Uplink Ports : 4x 1 Gigabit Ethernet SFP
- Management Ports : 1x USB-C Console Port 1x RJ-45 Console Port 1x OOBM 1x USB Type-A Host port
- Stacking Options : Stack Size = 8 members - Stacking Bandwidth = 40 Gbps
- CPU : Quad Core ARM Cortex A72 @ 1.8GHz
- Packet Buffer : 8 MB Packet Buffer Memory
- Fan Module Options : Fixed
- Power Supplies Included : 1x Fixed 500W AC PSU
- PoE Budget : Up to 370W of Class 4 PoE Power
- Switching Capacity : 128 Gbps
- Forwarding Rate : Up to 95.2 Mpps
- MAC Address Table Size : 32,768
- Latency : 1Gbps = 2.28μSec, 10Gbps = 1.46μSec
- DRAM and Flash : 8 GB DDR4 16 GB eMMC
- Model Number : S0M82A
- Part Number : S0M82A
- Condition : New
- One (1) NEW HPE Aruba S0M82A CX 6200F Series 24x 1GB PoE+ RJ45 4x 1GB SFP Switch as described above
