The HPE Aruba S0M85A CX 6200F Switch by Hewlett Packard Enterprise is a rack‑mountable unit featuring forty‑eight 1 GbE PoE+ RJ‑45 ports and four 1 GbE SFP uplink interfaces. It operates with a quad‑core ARM Cortex A72 processor at 1.8 GHz, supporting switching capacity of 176 Gbps and forwarding rate up to 130.9 Mpps.
This switch provides power delivery through PoE+, suitable for network devices such as access points or VoIP phones that require electrical supply over Ethernet cabling. The platform supports a MAC address table size of up to 32,768 entries and offers low latency measured at approximately 2.28 microseconds on 1 Gbps links and 1.46 microseconds on higher speed connections.
HPE Aruba S0M85A: HPE Aruba Networking CX 6200F 48G Class 4 PoE 4SFP 740W Switch.
- Network Ports : 48x 1 Gigabit Ethernet PoE+ RJ-45 - IEEE 802.3af
- Uplink Ports : 4x 1 Gigabit Ethernet SFP - also used for stacking
- Management Ports : 1x USB-C Console Port 1x RJ-45 Console Port 1x OOBM 1x USB Type-A Host port
- Stacking Ports : See "Uplink Ports"
- Stacking Options : Stack Size = 8 members. Stacking Bandwidth = 40 Gbps
- Stacking Cable Options : using long-range 10GbE transceivers and cables
- CPU : Quad Core ARM Cortex A72 @ 1.8GHz
- Packet Buffer : 8 MB Packet Buffer Memory
- Fan Module Options : Fixed
- Power Supplies Included : Fixed 950W AC PSU
- PoE Budget : Up to 740W of Class 4 PoE Power
- Switching Capacity : 176 Gbps
- Forwarding Rate : Up to 130.9Mpps
- MAC Address Table Size : 32,768
- Latency : 1Gbps = 2.28μSec, 10Gbps = 1.46μSec
- DRAM and Flash : 8 GB DDR4 16 GB eMMC
- Model Number : S0M85A
- Part Number : S0M85A
- Condition : New
- One (1) NEW HPE Aruba S0M85A CX 6200F 48x 1GB PoE+ RJ-45 4x 1GB SFP Switch as described above
