The HPE Aruba S0M82A CX 6200F Series is a rack-mountable switch manufactured by Hewlett Packard Enterprise. It features 24x 1GbE PoE+ RJ45 ports and 4x 1GbE SFP interfaces, supporting switching capacity of up to 128 Gbps with forwarding rates up to 95.2 Mpps.
This model supports Power over Ethernet Plus (PoE+) across all copper ports for efficient device connectivity. The quad-core ARM Cortex A72 processor runs at 1.8 GHz, suitable for enterprise edge deployments requiring moderate throughput levels. With support for static and dynamic Layer2/3 routing protocols, it integrates into mixed-traffic environments using standard mounting in network racks or enclosures via front-to-back airflow design options when applicable within the CX series configuration range.
HPE Aruba S0M82A: HPE Aruba Networking CX 6200F 24G Class 4 PoE 4SFP 370W Switch.
- Network Ports : 24x 1 Gigabit Ethernet PoE+ RJ45
- Uplink Ports : 4x 1 Gigabit Ethernet SFP
- Management Ports : 1x USB-C Console Port 1x RJ-45 Console Port 1x OOBM 1x USB Type-A Host port
- Stacking Options : Stack Size = 8 members - Stacking Bandwidth = 40 Gbps
- CPU : Quad Core ARM Cortex A72 @ 1.8GHz
- Packet Buffer : 8 MB Packet Buffer Memory
- Fan Module Options : Fixed
- Power Supplies Included : 1x Fixed 500W AC PSU
- PoE Budget : Up to 370W of Class 4 PoE Power
- Switching Capacity : 128 Gbps
- Forwarding Rate : Up to 95.2 Mpps
- MAC Address Table Size : 32,768
- Latency : 1Gbps = 2.28μSec, 10Gbps = 1.46μSec
- DRAM and Flash : 8 GB DDR4 16 GB eMMC
- Model Number : S0M82A
- Part Number : S0M82A
- Condition : Seller refurbished
- One (1) Seller refurbished HPE Aruba S0M82A CX 6200F Series 24x 1GB PoE+ RJ45 4x 1GB SFP Switch as described above
- One (1) Power Cord Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
