NEW Cisco C9300-24U-A Catalyst 9300 24x 1GB UPoE RJ45 1x Module Slot Switch
New

NEW Cisco C9300-24U-A Catalyst 9300 24x 1GB UPoE RJ45 1x Module Slot Switch

$ 3,392.99
$ 2,875.99
Only 1 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-1823
UPC: 889728051668

Overview

The Cisco C9300-24U-A Catalyst 9300 Switch is a powerful networking solution for efficient data transfer and high-speed connectivity. With 24 UPoE RJ45 ports, this switch delivers reliable power over Ethernet to connected devices, making it ideal for modern workplaces with multiple network requirements.

A notable feature of this Cisco switch is its PoE budget - up to 830W with the included 1100W AC PSU (increases further with additional PSUs). This means you can power various devices without needing extra power supplies.

Regarding performance, this switch has a switching capacity of up to 208 Gbps and a forwarding rate of 154.76 Mpps. These specifications ensure smooth data transmission within your network.

This catalyst model has an impressive MAC address table size of 32,000 entries, making it suitable for medium-sized networks or even larger ones if necessary

Cisco C9300-24U-A: Catalyst 9300 24x 1Gb RJ45 UPOE ports.


Specifications

  • Network Ports : 24x 1 Gigabit Ethernet UPOE RJ-45
  • Management Ports : 1x Management Console RJ-45, 1x Management Console RJ-45, 1x USB 3.0 SSD
  • Stacking Ports : 2x StackWise 480 Ports (480 Gbps Stacking Bandwidth), 2x StackPower Ports - Cables sold separately - Cable Options are STACK-T1-50CM, STACK-T1-1M, STACK-T1-3M, CAB-SPWR-30CM, CAB-SPWR-150CM
  • Module Slots and Options : 1x Expansion Module Slot - Modules are not included
  • Expansion Module Options : C9300-NM-4G, C9300-NM-8X, C9300-NM-2Q - Not Included - Sold Separately - Please note, existing 3850 network modules are also supported in the Cisco Catalyst 9300 Series platforms.
  • Fan Modules AirFlow Direction : 3x FAN-T2 Field Replaceable Fan Modules Included
  • Power Supplies Included : 1x PWR-C1-1100WAC 1100W AC PSU Included - 2x PSU Slots - 2nd PSU ordered separately - Options for 2nd PSU are PWR-C1-1100WAC, PWR-C1-715WAC, PWR-C1-350WAC
  • PoE Budget : 830W with 1x 1100W AC PSU - 1180W (with 350W 2nd PSU), 1440W (with 715W 2nd PSU), 1440W (with 1100W 2nd PSU)
  • Switching Capacity : 208 Gbps
  • Forwarding Rate : 154.76 Mpps
  • MAC Address Table Size : 32,000
  • Rack Mounts : Included (1-RU)
  • Model Number : C9300-24U-A
  • Part Number : C9300-24U-A, C9300-24U-A=, C9300-24U-A-WS
  • Condition : New


Included

  • One (1) NEW Cisco C9300-24U-A Catalyst 9300 24x 1GB UPoE RJ45 1x Module Slot Switch as described above
