The Cisco C9300-48U-A Catalyst 9300 Switch is a high-performance network switch designed for enterprise-level networks. It features 48x 1Gb ports with Universal Power over Ethernet (UPoE) 60W capability, allowing you to power devices such as IP phones and wireless access points directly from the switch.
This switch comes with one module slot, giving you the flexibility to expand your network capabilities. The PoE budget varies depending on the installed power supply unit - it can be either 822W (with default PSU), upgraded to higher wattages of 1172W, 1537W, or even up to 1800W using different PSUs.
With a switching capacity of 256 Gbps(736 Gbps when stacked), this switch ensures fast data transfer rates within your network. The forwarding rate reaches up to 190.48 Mpps (with stacking).
It also has an impressive MAC address table size that can store up to 32,000 addresses. This allows for efficient management and organization of connected devices in large-scale deployments
Cisco C9300-48U-M: Catalyst 9300-M 48x 1Gb RJ45 UPOE ports.
- Network Ports : 48x 1 Gigabit Ethernet UPoE RJ-45
- Product Family : Meraki Catalyst 9300-M Series
- Management Ports : 1x RS-232 RJ-45 Console, 1x Gigabit Ethernet Management, 1x USB 2.0 for configuration
- Stacking Ports : 2x StackWise 480 ports, 2x StackPower connection ports
- Stack Members : Up to eight switches can be connected in the stack | Supported stack members = Other C9300 SKUs with same license level - C9300 higher scale SKUs only stack with other like higher scale models
- Stacking Cable Options : Stackwise - STACK-T1-50CM-M, STACK-T1-1M-M, STACK-T1-3M-M | StackPower - CAB-SPWR-30CM-M, CAB-SPWR-150CM-M
- Module Slots : 1x Expansion Module Slot - None Included - Sold separately
- Module Options : C9300-NM-4G-M, C9300-NM-8X-M, C9300-NM-2Q-M, C9300-NM-4M-M, C9300-NM-2Y-M
- AirFlow Direction : Front-to-Back Airflow
- Fan Module Options : 3x FAN-T2-M Field Replaceable Fan Modules Included
- Power Supplies Included : 1x PWR-C1-1100WACP-M Power Supply included - 2x Slots
- Power Supply Options : PWR-C1-715WAC-P-M, PWR-C1-350WAC-P-M, PWR-C1-1100WAC-P-M
- PoE Budget : 822W (w/ Default PSU), 1172W (w/ 350W 2nd PSU), 1537W (w/ 715W 2nd PSU), 1800W (w/ 1100W 2nd PSU)
- Switching Capacity : 256 Gbps (736 Gbps with Stacking)
- Forwarding Rate : 190.48 Mpps (547.62 Mpps with Stacking)
- MAC Address Table Size : 32,000
- DRAM and Flash : DRAM 8GB, 16GB Flash
- Model Number : C9300-48U-M
- Part Number : C9300-48U-M
- Condition : Seller refurbished
- One (1) Seller Refurbished Cisco Meraki C9300-48U-M 48x 1GB UPoE RJ-45 1x Module Slot Unclaimed Switch as described above
- One (1) Power Cord Included
- One (1) AC Power Supply Included
- Three (3) Fan Modules Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
- Network Modules Not Included
