The Cisco CW9164I-MR offers Antenna Options with Spread Spectrum Method of OFDMA, supporting Frequency Bands of 2.4 GHz, 5 GHz, and 6 GHz. Its Internal antenna can handle Data Link Protocol efficiently for IoT applications. The regulatory domain includes Bluetooth Low Energy (LE) technology for seamless connectivity.
With a Maximum Data Rate suitable for Internet of Things devices and compatibility across various communication technologies such as Wi-Fi and Bluetooth LE, the Cisco CW9164I-MR provides reliable performance in diverse environments requiring wireless connections at different frequencies.
Cisco CW9164I-MR: Meraki CW9164I cloud-managed 802.11ax compatible AP.
- Interface Ports : 1x 100M/1000M/2.5G BASE-T Ethernet RJ-45, 1x USB 2.0 Type-A (4.5W power budget)
- Uplink options : The single RJ-45 port supports speeds of 100M/1000M/2.5G and serves as both the data and uplink interface.
- Management Ports : No dedicated management port
- Antenna Ports : No external antenna ports - integrated omnidirectional antennas only
- Antenna Options : Integrated omnidirectional antennas, 3 dBi at 2.4 GHz, 5 dBi at 5 GHz, 4 dBi at 6 GHz
- Power Options : The CW9164I-MR is powered via 802.3bt UPOE (42.5 to 57V) or PoE+ 802.3at, or an alternative 54V DC input. PoE injector (MA-INJ-6) and DC adapter (MA-PWR-50WAC) sold separately.
- Frequency : 2.4 GHz, 5 GHz, 6 GHz
- Data Link Protocol : IEEE 802.11a/b/g/n/ac/ax
- Licence : Unclaimed - Licence can be purchased directly from Meraki
- Maximum Data Rate : Indoor
- Regulatory domain : 7.49 Gbps (Aggregate, Tri-band)
- Mounts : Ceiling, Wall Mount. All Cisco standard mounting hardware supported (AIR-AP-BRACKET-2 included). Compatible with AIR-AP-BRACKET-1 and AIR-AP-BRACKET-2. Ceiling tile rail support for 9/16, 15/16, or 1.5 in. flush or recessed rails
- Model Number : CW9164I-MR
- Part Number : CW9164I-MR
- Condition : New
- One (1) NEW Cisco Meraki CW9164I-MR High-Performance CloudManaged 802.11ax Unclaimed WAP as described above
