HPE Aruba JL075A 3810 Series 16x 10GB SFP+ 2x Expansion Module Slot Switch

HPE Aruba JL075A 3810 Series 16x 10GB SFP+ 2x Expansion Module Slot Switch

$ 1,856.99
$ 1,482.99
Only 1 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.   Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: Seller refurbished
Pre-owned, tested by qualified techs, working, reset-to-factory default, grade A condition, and parts needed for normal functions are included (as described in the listing).
Warranty: 365 days
Warranty coverage period
SKU: NSH-5952
UPC: 888793596616

Overview

The HPE Aruba JL075A 3810 Series Switch is a high-performance network switch designed to meet the demands of modern data centers and enterprise networks. Its 16x 10GB SFP+ ports provide blazing-fast connectivity for your devices.

This switch boasts a capacity of up to 480 Gbps, ensuring seamless transmission of large amounts of data across multiple connections. The forwarding rate reaches 285.7 Mpps (million packets per second), guaranteeing efficient packet routing with minimal latency.

With a MAC address table size of up to 64,000 entries, the JL075A can handle even the most complex network environments without compromising performance or security. Speaking about security measures found on such switches- X-Wires ensure that suspicious traffic is quickly identified and blocked from penetrating your system based on predetermined customizable policies.

HPE Aruba JL075A: 16x SFP+ fixed 1000/10000 SFP+ ports; Duplex: 100BASE-TX: half or full; 1000BASE-T: full only;. Ports - 16x support MACSec. 2x open module slots. Supports 8x SFP+ ports or 2x 40 GbE ports, with an optional module.


Specifications

  • Network Ports : 16x 10 Gigabit Ethernet SFP+
  • Management Ports : 1x RJ45 Console, 1x Out-of-Band Management, 1x Dual-Personality (RJ45 or USB micro-B), 1x USB/AUX
  • Stacking Ports : 1x Stacking Module Slot - The JL084A Stacking Module is not included
  • Stacking Options : High-performance stacking provides up to 336 Gbps of stacking throughput; each 4-port stacking module can support up to 42 Gbps in each direction per stacking port
  • Stacking Cable Options : J9578A (0.5m), J9665A (1m), J9579A (3m)
  • Module Slots : 2x Expansion Module Slots - Modules are not included - Sold Separately
  • Module Options : JL079A (2x 40GB QSFP+), JL078A (1x 40GB QSFP+), JL081A (4x 10GB SFP+), JL083A (4x 10GB SFP+)
  • Fan Module Options : 1x JL088A Aruba 3810 Switch Fan Tray Included
  • Power Supplies Included : None - 2x Power Supply slots - 1 Minimum Power Supply Required
  • Power Supply Options : Ordered Separately - Options are JL085A (250W AC), JL086A (680W AC), JL087A (1050W AC)
  • Switching Capacity : 480 Gbps
  • Forwarding Rate : 285.7 Mpps
  • MAC Address Table Size : 64000
  • Latency : < 2.8 nanoseconds (FIFO 64-byte packets) (1000MB)
  • Model Number : JL075A
  • Part Number : JL075A, JL075A#ABA
  • Condition : Seller refurbished

Datasheet

More information on this HPE JL075A.

Included

  • One (1) Seller Refurbished Aruba HPE JL075A 3810 Series 16x 10GB SFP+ 2x Free Expansion Module Slot Switch as described above
  • One (1) Fan Module Included
  • One (1) Set of Rack Mount Brackets Included

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
  • Power Supplies Not Included
  • Network Modules Not Included
  • Transceiver Modules Not Included
