NEW HPE Aruba JL725A CX 6200 Series 24x 1GB RJ-45 (4x PoE) 4x 10GB SFP+ Switch
New

NEW HPE Aruba JL725A CX 6200 Series 24x 1GB RJ-45 (4x PoE) 4x 10GB SFP+ Switch

$ 1,624.99
$ 1,539.99
7 in stock
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-9836
UPC: 190017408507

Overview

The HPE Aruba JL725A CX 6200 Series is a high-performance switch designed for small to midsize enterprises. With 24 RJ-45 ports, including 4 with Power over Ethernet (PoE), and 4 SFP+ slots, this switch provides flexibility in network connectivity.

With a PoE budget of up to 370W, it can power devices such as IP phones or wireless access points without additional power sources. The switching capacity of up to 128 Gbps allows for fast data transfer and efficient handling of network traffic.

Equipped with a MAC address table size of 16,000 entries, this switch offers ample space for storing device addresses. It also boasts low latency rates - an average latency rate ranging from 2.28 microseconds to 1 Gbps packets and 1.46 microseconds for 10Gbps, which offers smooth communication between connected devices.


Specifications

  • Network Ports : 24x 1 Gigabit Ethernet RJ-45 (4x PoE)
  • Uplink Ports : 4x 10 Gigabit Ethernet SFP+
  • Management Ports : 1x USB-C Console, 1x OOBM, 1x USB Type-A Host, 1x Bluetooth dongle to be used with Aruba CX Mobile App
  • Stacking Ports : The Aruba Virtual Switching Framework (VSF) allows you to quickly grow your network using high performance front plane stacking. The 4x 10GB SFP+ ports support speeds of 1GbE and 10GbE
  • Stack Size : Up to 8 Members | Switched Virtual Interfaces (dual stack) = 128
  • Fan Modules AirFlow Direction : Fixed fans
  • Power Supplies Included : 1x Internal 500W AC PSU
  • PoE Budget : 370W
  • Switching Capacity : 128 Gbps
  • Forwarding Rate : Up to 95.2 Mpps
  • MAC Address Table Size : 16,000
  • Average Latency (LIFO-64-bytes packets) : 1 Gbps = 2.28 μSec, 10 Gbps = 1.46 μSec
  • Rack Mounts : Included (1-RU)
  • Model Number : JL725A
  • Part Number : JL725A
  • Condition : New


Included

  • One (1) NEW HPE Aruba JL725A CX 6200 Series 24x 1GB RJ-45 (4x PoE) 4x 10GB SFP+ Switch as described above
