The NEW HPE Aruba JX940A IAP-304 (US) is a high-performance wireless access point that delivers fast and reliable Wi-Fi connectivity. With support for the latest 802.11ac standard, this WAP offers up to 1.7 Gbps speeds, ensuring seamless streaming and smooth browsing experiences.
Equipped with MU-MIMO (multiple-user, multiple-input, multiple-output) technology, the IAP-304 allows efficient simultaneous connections to multiple devices without sacrificing performance or speed. Its dual-band functionality operates in both the 2.4 GHz and 5 GHz frequencies, maximizing coverage while minimizing interference.
Designed with simplicity, this access point can be set up quickly using its Instant firmware, eliminating complex configuration processes traditionally associated with enterprise-grade equipment.
NEW HPE Aruba JX940A IAP-304 (US) Instant 802.11ac 2x2:2/3x3:3 MU-MIMO WAP
- Wi-Fi Standard : 802.11ac Wave 2 (Wi-Fi 5), MU-MIM
- Managed By : Aruba Instant (controller-less) / Aruba Central
- Suggested Use : Indoor, medium density environments
- Region : United States (US)
- Radios : Dual Radio - 5GHz 802.11ac 3x3 MIMO & 2.4GHz 802.11n 2x2 MIMO
- Spatial Streams per Radio : 5GHz 3SS / 2.4GHz 2SS
- Maximum Data Rate : 1.6 Gbps aggregate (1,300 Mbps 5GHz + 300 Mbps 2.4GHz)
- Bluetooth / IoT Radios : Bluetooth Low Energy (BLE), optional Zigbee IoT expansion radio
- PoE Standard : 802.3af / 802.3at
- DC Power Input : 12V DC nominal ±5% (2.1/5.5mm center-positive jack) - adapter not included
- Uplink Ports : 1x 10/100/1000BASE-T (RJ-45)
- Other Ports : 1x USB 2.0 Type-A
- Antenna Type : External (RP-SMA connectors)
- Antenna Ports : 3x dual-band RP-SMA connectors
- Antenna Options : JW009A, JW001A, JW003A, JW004A, JW011A, JW015A, JW016A
- Mounting Options : JY705A - White Low Profile Box Style AP Flat Surface Mount Kit, AP-305-CVR-20 (JX951A) - Snap on cover - Neither Included
- Mounts Included : The AP ships with two (black) mounting clips to attach to a 9/16-inch or 15/16-inch flat T-bar drop-tile ceiling
- Model Number : JX940A
- Part Number : JX940A, IAP-304, IAP-304-US
- Condition : New
- One (1) NEW HPE Aruba IAP-304 JX940A Wi-Fi 5 802.11ac External Antenna Wireless AP as described above
