NEW Cisco Meraki MR36H-HW Wi-Fi 6 802.11ax Wall Switch Unclaimed WAP w/ Mounts

$ 789.99
$ 766.99
40 in stock
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-0128 ASK FOR QUOTE
UPC: 810979018636

Overview

The Cisco Meraki MR36H-HW is a Wi-Fi 6 (802.11ax) wall-plate access point that mounts over a wall box inside the room, managed from the Meraki cloud dashboard. It is built for hotel rooms, dormitories, apartments, senior living, and clinic rooms, where each room needs its own Wi-Fi and a few wired ports for a TV, phone, or set-top box.

It runs 2x2:2 on both 2.4 GHz and 5 GHz, for up to 1.5 Gbps combined radio rate, plus a dedicated radio that scans full-time for security threats and RF interference, and a Bluetooth Low Energy radio. It has a Gigabit uplink, three managed Gigabit ports for in-room devices (one with 802.3af PoE output), and an unmanaged passthrough port.

Power it with 802.3at PoE+ to turn on the PoE output. On standard 802.3af PoE, it runs in low-power mode: Wi-Fi and the wired ports keep working, but the PoE output port stops supplying power. It ships with its wall mount and is sold unclaimed, so you can claim it into your own Meraki organization. A Meraki license is required and is sold separately. Covered by our 365-day warranty.

NEW Cisco Meraki MR36H-HW: Wi-Fi 6 802.11ax wall-plate AP, 2x2:2 dual-band, dedicated scanning radio, BLE, 1x Gigabit uplink, 3x Gigabit access ports (1x PoE out), passthrough port, unclaimed.


Specifications

  • Wi-Fi Standard : Wi-Fi 6 (802.11ax)
  • Managed By : Cloud Managed
  • Licensing : Licence is not included - these can be purchased directly from Meraki - this unit is unclaimed
  • Suggested Use : The MR36H makes an outstanding platform for the most demanding of uses - including high-density deployments and bandwidth or performance-intensive applications like voice and high-definition video
  • Region : US
  • Spatial Streams per Radio : 2
  • Maximum Data Rate : 1.5 Gbps - with up to 1,201 Mbps in the 5 GHz band and 286 Mbps in the 2.4 GHz band
  • Bluetooth / IoT Radios : 1x Bluetooth Low Energy Beacon and scanning radio (See "Radios" above)
  • PoE Standard : Power over Ethernet = 37 - 57 V (802.3at compatible) - Power over Ethernet injector sold separately
  • DC Power Input : None - PoE Only
  • Uplink Ports : 1x 1 Gigabit Ethernet PoE RJ-45 (802.3af)
  • Other Ports : 2x 1 Gigabit Ethernet RJ-45 Output, 1x 1 Gigabit Ethernet RJ-45 Uplink (on back of unit), 1x Passthrough port
  • Antenna Type : Internal Omni-Directional Antenna (5.4 dBi gain at 2.4 GHz, 6 dBi gain at 5 GHz)
  • Antenna Ports : None - Internal Antenna
  • Mounting Options : MA-MNT-MR-H2 - Designed specifically for wall plate/junction box installations
  • Mounts Included : MA-MNT-MR-H2 Included - Includes the front and rear panels of the accessory, two 12mm Phillips head screws, and a keystone jack port.
  • Model Number : MR36H-HW
  • Part Number : MR36H-HW, MR36H-HW=, MR36H-HW-WS
  • Condition : New


Included

  • One (1) NEW Cisco Meraki MR36H-HW Wi-Fi 6 802.11ax Wall Switch Unclaimed WAP w/ Mounts Used as described above
