NEW Dell N3248PXE-ON 48x 10GB PoE Copper 4x SFP28 2x QSFP28 F-B Air OS6 Switch

$ 6,899.99
Only 1 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-9977 ASK FOR QUOTE

Overview

The NEW Dell N3248PXE-ON is a powerful switch designed to meet the demands of high-performance networking environments. Its 48x 10GB PoE copper ports provide ample connectivity options for your network devices. Including 4x SFP28 and 2x QSFP28 ports enhances flexibility by allowing fiber connections.

This switch features a switching capacity of up to 1560Gbps, ensuring smooth and efficient data transmission throughout your network. Coupled with a forwarding rate of up to 2167Mpps, this results in minimal latency and optimized performance.

With a PoE budget of up to 90W per port, the N3248PXE-ON supports power-hungry devices such as IP cameras or wireless access points without additional power supply requirements.

NEW Dell N3248PXE-ON 48x 10GB PoE Copper 4x SFP28 2x QSFP28 F-B Air OS6 Switch


Specifications

  • Network Ports : 48x 10 Gigabit Ethernet PoE RJ45 (10M/100M/1G/2.5G/5G/10G)
  • Uplink Ports : 4x 25 Gigabit Ethernet SFP28, 2x 100 Gigabit Ethernet QSFP28 (On Rear of Switch)
  • Management Ports : 1x USB, 1x Micro USB, 1x RJ45 Console with RS232 signalling
  • Packet Buffer Memory : 8MB
  • Switch Version : OS6
  • AirFlow Direction : Front-to-Back Airflow - I/O to PSU
  • Fan Module Options : 3x Fan Modules Included (4x Total Slots)
  • Power Supplies Included : 2x PSU Slots - 1x 1600W AC PSU Included (Manufacturer Part YW4FN | Dell Part 282-BBBE)
  • PoE Budget : 90W
  • Switching Capacity : 1560 Gbps
  • Forwarding Rate : 2167 Mpps
  • MAC Address Table Size : 32K
  • Model Number : N3248PXE-ON
  • Part Number : N3248PXE-ON
  • Condition : New


Included

  • One (1) NEW Dell N3248PXE-ON 48x 10GB PoE Copper 4x SFP28 2x QSFP28 F-B Air OS6 Switch as described above
