NEW Cisco N9K-C9316D-GX Nexus 9300-GX 16x 400GB QSFP-DD F-B Airflow Switch
New

NEW Cisco N9K-C9316D-GX Nexus 9300-GX 16x 400GB QSFP-DD F-B Airflow Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-9641
UPC: 882658798580

Overview

The Cisco N9K-C9316D-GX Nexus 9300-GX switch offers a high switching capacity of 12.8 Tbps and a forwarding rate of 4.3 Bpps, making it ideal for data-intensive applications. With a MAC address table size of up to 256,000 entries and support for up to 4096 VLANs, this switch provides scalability for growing networks.

The low latency ensures fast data transfer speeds, while the QSFP-DD ports allow connectivity up to 400Gbps per port. Whether used in large enterprises or service providers' environments requiring high throughput and reliability levels, achieving optimal network performance is possible with the Cisco N9K-C9316D-GX Nexus Switch.

Cisco Nexus 9316D: Spine switch with 16p 400/100G QSFP-DD


Specifications

  • Network Ports : 16x 400 Gigabit Ethernet QSFP-DD ports
  • Port Supported Speeds : 40/100/400-Gbps Ethernet, Breakout supported on all ports, 1-16 - 2x200, 4x100, 2x100, 8x50, 4x50, 2x50, 4x25, 4x10, 10G w/QSA
  • Management Ports : 1x RJ45 and 1x SFP, 1x USB, 1x RS232
  • SSD : 128 GB
  • AirFlow Direction : Front-to-Back Airflow
  • Fan Modules Included : 6x NXA-FAN-35CFM-PI Fan Modules Included
  • Fan Module Options : NXA-FAN-35CFM-PI (F-B Airflow), NXA-FAN-35CFM-PE (B-F Airflow)
  • Power Supplies Included : 2x NXA-PAC-1100W-PI2 PSU Included
  • Power Supply Options : Port side intake - NXA-PAC-1100W-PI2 (AC-Spare), NXA-PDC-1100W-PI2 (DC-Spare) NXA-PHV-1100W-PI (HV-AC-DC), Port side Exhaust - NXA-PAC-1100W-PE2 (AC-Spare), NXA-PDC-1100W-PE2 (DC-Spare) NXA-PHV-1100W-PE (HV-AC-DC),
  • Switching Capacity : 12.8 Tbps
  • Forwarding Rate : 4.3 Bpps
  • MAC Address Table Size : 256,000
  • Max IPv4 Host Entries : 896,000 (Longest Prefix Match)
  • Max IPv4 LPM Routes : 896,000
  • Multicast routes : 32,000
  • Virtual interfaces (VLANs) : 4096 (Max)
  • Packet Buffer : 80 MB
  • DRAM and Flash : 32 GB (DRAM), System Buffer - 80 MB, CPU - 4 Core
  • Model Number : N9K-C9316D-GX
  • Part Number : N9K-C9316D-GX, N9K-C9316D-GX=, N9K-C9316D-GX-WS
  • Condition : New


Included

  • One (1) NEW Cisco N9K-C9316D-GX Nexus 9300-GX 16x 400GB QSFP-DD F-B Airflow Switch as described above

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
  • Transceiver Modules Not Included
  • Rack Mount Brackets/Rails Not Included
