A NEW Cisco Catalyst C9300L-48UXG-2Q-E (Network Essentials version), supplied in open box, powers access points and phones at up to 60W per port from 48 UPOE ports, with two fixed 40G uplinks and optional stacking.
- Budget up to 1,775W: 675W of PoE comes from the default 1100W supply. Cisco lists 1,390W with a 715W second supply and 1,775W with an 1100W one.
- Fixed 40G uplinks: Two QSFP+ uplinks are built in at 40G. A C9300L-48UXG-4X has four 10G/1G SFP+ uplinks if you want slower, more numerous links.
- Stacking runs through a kit: Stacking uses the optional C9300L-STACK-KIT or C9300L-STACK-KIT2, and up to eight Catalyst 9300L switches share 320 Gbps.
- Swappable fans, spare bay: The three N+1 fans (FAN-T2) are field-replaceable, and a second power supply bay is open for redundancy.
Compare: Want fewer ports? The NEW C9300L-24UXG-2Q-E has 24 UPOE ports. Don't need UPOE? The NEW C9300L-48T-4X-E is data-only.
What ships with this unit is listed under What's Included. See all Cisco Catalyst 9300 switches and parts.
This unit is NEW in open box and sold with warranty. Need several, or a matched set with power supplies and fans? Ask us for a quote.
- Network Ports : 36x 1 Gigabit Ethernet RJ45 UPOE ,12x MultiGigabit Ethernet RJ45
- Uplink Ports : 2x 40 Gigabit Ethernet QSFP+
- Management Ports : 2x USB, 1x Mini USB
- Stack Technology : StackWise-320
- Stacking Options : C9300L-STACK-KIT - Ordered Separately
- Stacking Cable Options : STACK-T3-3M, STACK-T3-1M, STACK-T3-50CM - None Included
- Switch Version : Network Essentials
- Fan Module Options : 3x FAN-T2 Modules Included
- Power Supplies Included : 1x PWR-C1-1100WAC-P Included - 2nd Power Supply ordered separately.
- PoE Budget : 675W
- Switching Capacity : 472 Gbps (Switching Capacity with Stacking - 792 Gbps)
- Forwarding Rate : 351.19 Mpps (Forwarding Rate with Stacking - 589.28 Mpps)
- MAC Address Table Size : 32,000
- Model Number : C9300L-48UXG-2Q-E
- Part Number : C9300L-48UXG-2Q-E, C9300L-48UXG-2Q-E=, C9300L-48UXG-2Q-E-WS
- Condition : New
- One (1) NEW Cisco C9300L-48UXG-2Q-E 48x 1GB UPoE RJ45 (12x MultiGB) 2x QSFP+ Switch as described above
