For racks of servers with 10GBASE-T onboard, the 7160-48TC6 offers 48 RJ-45 ports at 1G or 10G and six QSFP uplinks at 40G or 100G in a 1RU chassis. Servers connect over standard copper cabling while the uplinks reach the spine at 100G.
Arista rates it at 2.16 Tbps and 2.4 Bpps, with latency from 3 microseconds and a 24 MB fully shared packet buffer. The control plane runs a quad-core x86 CPU with 8 GB RAM and 4 GB flash. Power draw is 408W typical and 482W maximum.
Two AC power supplies are installed in a 1+1 redundant, hot-swap pair, using C13-C14 cords. Spares are PWR-500AC-F and PWR-500-DC-F for DC. Four hot-swap FAN-7000H-F fans in N+1 move air front-to-back (port-side intake). A back-to-front version is also available, so keep fans and supplies matched to the rack.
Management uses a 100/1000 RJ-45 port, an RJ-45 RS-232 console and two USB ports. The switch weighs 20.42 lb. Advanced Layer 3 features such as BGP and OSPF need an Arista Enhanced L3 license, which is not included and is available from Arista partners.
Arista also sells the DCS-7160-48TC6-R with the opposite airflow. A new DCS-7160-48TC6-F is also available. Matching spares include the PWR-500AC-F power supply and the FAN-7000H-F fan module.
This seller refurbished DCS-7160-48TC6-F is tested, working, and covered by the NetworkTigers one-year warranty.
- Network Ports : 48x 10GBASE-T RJ-45 (1/10G)
- Uplink Ports : 6x 100G QSFP (40/100G)
- Management Ports : 1x 100/1000 RJ-45 mgmt, 1x RS-232 RJ-45 console, 2x USB
- CPU : Quad-Core x86
- VLAN ID's : 4096
- Packet Buffer : 24MB
- Switch Version : Arista EOS
- AirFlow Direction : front-to-back (port-side intake)
- Fan Module Options : FAN-7000H-F
- Power Supplies Included : 2x AC (1+1 redundant, hot-swap)
- Power Supply Options : PWR-500AC-F, PWR-500-DC-F (DC)
- PoE Budget : None
- Switching Capacity : 2.16 Tbps
- Forwarding Rate : 2.4 Bpps
- MAC Address Table Size : 128,000
- Latency : from 3 microseconds
- DRAM and Flash : 8 GB RAM, 4 GB flash, Quad-Core x86 CPU
- Model Number : DCS-7160-48TC6-F
- Part Number : DCS-7160-48TC6-F
- Condition : Seller refurbished
- One (1) Seller Refurbished Arista DCS-7160-48TC6-F 48x 10GB Copper 6x 100GB QSFP Front-to-Back Air Switch as described above
- Two (2) Power Cords Included
- Two (2) AC Power Supplies Included
- Four (4) Fan Modules Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
