The Fortinet FS-224E-POE 200 Series Switch is a reliable choice for network connectivity needs. With 24 RJ45 ports (12 PoE) and 4 SFP ports, this switch offers versatility for connecting a wide range of devices. The PoE budget of 180 W allows for efficient power distribution to compatible devices.
Operating at speeds up to 1GB, with a switching capacity of 56 Gbps and a forwarding rate of 83 Mpps, the FS-224E ensures optimal data transfer rates across your network. With a MAC address table of 16,000 and a latency of less than 1 µs, this switch delivers stable performance under heavy loads without compromising speed or reliability. Suitable for small to medium-sized networks requiring Power over Ethernet capabilities.
Fortinet FS-224E-POE: Layer 2/3 FortiGate switch controller compatible PoE+ switch with 24 GE RJ45 + 4 SFP ports, 12 port PoE with maximum 180 W limit. This unit is not registrable on the FortiCloud - it is set up for local management only.
- Network Ports : 24x 1 Gigabit Ethernet RJ45 (12x PoE+)
- Uplink Ports : 4x 1 Gigabit Ethernet SFP
- Management Ports : 1x RJ45 Serial Console, 1x Gigabit Management RJ45
- Registrable : No - This unit is not registrable on the FortiCloud - it is set up for local management only
- VLAN's Supported : 4 K
- Packet Buffer : 1.5 MB
- AirFlow Direction : Side to Back Airflow
- Power Supplies Included : 1x Internal AC Power Supply - 100–240V AC, 50–60 Hz
- Power Supply Options : Optional FRPS-740 (Redundant Power)
- PoE Budget : 180 W
- Switching Capacity : 56 Gbps
- Forwarding Rate : 83 Mpps
- MAC Address Table Size : 16,000
- Latency : < 1µs
- DRAM and Flash : DRAM = 512 MB, Flash = 128 MB
- Model Number : FS-224E-POE
- Part Number : FS-224E-POE
- Condition : New
- One (1) NEW Fortinet FS-224E-POE 200 Series 24x 1GB RJ45 Local Management Only Switch as described above
