NEW Fortinet FS-M426E-FPOE 26x RJ45 4x SFP+ Local Management Only Switch
New

NEW Fortinet FS-M426E-FPOE 26x RJ45 4x SFP+ Local Management Only Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-8437

Overview

The NEW Fortinet FS-M426E-FPOE switch offers 26 RJ45 ports with various speeds to accommodate network requirements. With a PoE budget of up to 24, the switch can power multiple devices without additional equipment.

It has a switching capacity of 172 Gbps and a forwarding rate of 255 Mpps, ensuring efficient data transfer within the network. The MAC Address Table Size is sufficient for managing connections in medium-sized networks, while low latency guarantees minimal delays during data transmission.

This switch provides reliable performance for organizations looking to enhance their network infrastructure with high-speed connectivity options and Power over Ethernet capabilities.

Layer 2/3 FortiGate switch controller compatible PoE+/802.3bt Type 3 switch with 16x GE RJ45, 8x 2.5 RJ45, 2x 5 GE RJ45 and 4x 10 GE SFP+, 24 port PoE+ with maximum 420 W limit. This unit is not registrable on the FortiCloud - it is set up for local management only.


Specifications

  • Network Ports : 16x 1 Gigabit Ethernet RJ45, 8x 2.5 Gigabit Ethernet RJ45, 2x 5 Gigabit RJ45 (24x PoE+) - (16x 802.3af/at, 8x 802.3af/at/bt Type 3)
  • Uplink Ports : 4x 10 Gigabit Ethernet SFP+
  • Management Ports : 1x RJ45 Serial Console, 1x 1 Gigabit Management RJ45
  • Registrable : No - This unit is not registrable on the FortiCloud - it is set up for local management only
  • VLAN's Supported : 4 K
  • AirFlow Direction : Side to Back Airflow
  • Power Supplies Included : 1x Internal AC Power Supply
  • PoE Budget : 420 W
  • Switching Capacity : 172 Gbps
  • Forwarding Rate : 255 Mpps
  • MAC Address Table Size : 16,000
  • Latency : < 1µs
  • DRAM and Flash : Flash = 256 MB, DRAM = 1 GB DDR4
  • Model Number : FS-M426E-FPOE
  • Part Number : FS-M426E-FPOE
  • Condition : New


Included

  • One (1) NEW Fortinet FS-M426E-FPOE 26x RJ45 4x SFP+ Local Management Only Switch as described above
