HPE Aruba JL071A 3810 Series 24x 1GB RJ-45 1x Expansion Module Slot Switch

HPE Aruba JL071A 3810 Series 24x 1GB RJ-45 1x Expansion Module Slot Switch

$ 1,439.99
$ 1,057.99
Only 2 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: Seller refurbished
Pre-owned, tested by qualified techs, working, reset-to-factory default, grade A condition, and parts needed for normal functions are included (as described in the listing).
Warranty: 365 days
Warranty coverage period
SKU: NSH-5951
UPC: 888793596579

Overview

The HPE Aruba JL071A 3810 Series switch is a powerful networking solution with exceptional performance and scalability. With its 24x 1GB RJ-45 ports and an expansion module slot, it can easily handle high volumes of data traffic.

This JL071A has a switching capacity of up to 160 Gbps, ensuring fast and reliable connectivity for your network. It also boasts a forwarding rate of 95.2 Mpps (million packets per second), allowing smooth data transmission even during heavy workloads.

With a MAC address table size of 64,000 entries, this switch accommodates large networks without having an effect on efficiency or speed. Its low latency ensures minimal delay in packet delivery – less than 2.8 microseconds for FIFO-based packets measuring at the optimum length (64 bytes).

Aruba JL071A: 24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only; Ports 1 - 24 support MACSec 1 open module slot. It supports a maximum of 4 SFP+ ports or 1x 40 GbE ports, with an optional module.


Specifications

  • Network Ports : 24x 1 Gigabit Ethernet RJ-45
  • Product Family : Aruba 3810 Series
  • Management Ports : 1x RJ-45 Serial Console, 1x Gigabit Management Rj-45, 1x Mini-USB Type B Console, 1x USB/AUX
  • Stacking Ports : 1x Stacking Module Slot - The JL084A Stacking Module is not included - High-performance stacking provides up to 336 Gbps of stacking throughput; each 4-port stacking module can support up to 42 Gbps in each direction per stacking port, Stacking Cable Opti
  • Module Slots and Options : 1x Expansion Module Slot - None Included - Options are - JL079A (2x 40GB QSFP+), JL078A (1x 40GB QSFP+), JL081A (4x 10GB SFP+), JL083A (4x 10GB SFP+)
  • Fan Modules AirFlow Direction : 1x JL088A Aruba 3810 Switch Fan Tray Included
  • Power Supplies Included : 2x Slots (Min 1x Required) - Ordered Separately - options are - JL085A (250W AC), JL086A (680W AC), JL087A (1050W)
  • Stacking Members : Ring, chain, and mesh topologies support up to a 10-member ring or chain and 5-member fully meshed stacks; meshed topologies offer increased resiliency vs. a standard ring
  • Switching Capacity : 160 Gbps
  • Forwarding Rate : 95.2 Mpps
  • MAC Address Table Size : 64,000
  • Latency : < 2.8 µs (FIFO 64-byte packets) (1000MB)
  • Rack Mounts : Included (1-RU)
  • Model Number : JL071A
  • Part Number : JL071A
  • Condition : Seller refurbished


Included

  • One (1) Seller Refurbished Aruba HPE JL071A 3810 Series 24x 1GB RJ-45 1x Expansion Module Slot Switch as described above
  • One (1) Fan Module Included
  • One (1) Set of Rack Mount Brackets Included

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
  • Transceiver Modules Not Included
