The HPE Aruba JL321A 2930M is a high-performance switch designed for enterprise networks. With its switching capacity of 176 Gbps and a forwarding rate of 112 Mpps, it delivers fast and reliable data transmission.
Equipped with 44x1GB RJ-45 ports, 4x1GB Combo ports, and one module slot, this switch offers flexibility in network connectivity options. The MAC address table size supports up to 32,768 entries, ensuring efficient handling of network traffic.
With low latency at under3.1μs (FIFO64-byte packets), the JL321A delivers speedy response times for critical applications such as VoIP or video streaming.
Aruba JL321A: 44 Autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASETX, IEEE 802.3ab Type 1000Base-T); Duplex: 10BASE-T/100BASE-TX: half or full;1000BASE-T: full only.
- Network Ports : 44x 1 Gigabit Ethernet RJ-45
- Uplink Ports : 4x 1 Gigabit Combo (1 Gigabit Ethernet RJ-45 or 1G SFP)
- Management Ports : 1x Dual Personality Serial Console, 1x USB Type B, 1x Out of Band Management,
- Stacking Ports : 1x Stacking Module Slot - Not included - Stacking Performance = 100Gbps
- Stacking Cable Options : J9734A (0.5m), J9735A (1m), J9736A (3m)
- Module Slots : 1x Expansion Module Slot - Modules are not included
- Module Options : JL078A (1x 40GB QSFP+), JL083A (4x 10GB SFP+ MACsec), JL081A (4x 1/2.5/5/10GB RJ-45 SmartRate) - None Included
- Fan Module Options : Internal
- Power Supplies Included : 2x Power Supply Slots - PSU's not included - 1x PSU required
- Power Supply Options : Options are JL085A
- Switching Capacity : 176 Gbps
- Forwarding Rate : 112 Mpps
- MAC Address Table Size : 32768
- Latency : < 3.1µs (FIFO 64-byte packets) (1000MB)
- Model Number : JL321A
- Part Number : JL321A, 2930M 48G
- Condition : New
- One (1) NEW HPE Aruba JL321A 2930M 44x 1GB RJ-45 4x 1GB Combo 1x Module Slot Switch as described above
