HPE Aruba JL727B is a fixed‑configuration rack‑mount switch from Hewlett Packard Enterprise featuring 48 × 1 GbE Class 4 PoE RJ‑45 ports and 4 × 10 GbE SFP+ uplink interfaces. It provides a switching capacity of 176 Gbps and a forwarding rate of up to 130.9 Mpps, with latency of 2.28 µSec at 1 GbE and 1.46 µSec at 10 GbE.
The switch is powered by a quad‑core ARM Cortex™‑A72 processor at 1.8 GHz and supports a MAC address table size of 32,768 entries. The 48 PoE ports supply Class 4 power to connected devices such as IP phones, wireless access points, and surveillance cameras. Four 10 GbE SFP+ ports support fiber uplinks to aggregation or core switches. The unit is designed for standard rack installation.
HPE Aruba JL727B: CX 6200F 48G Class-4 PoE 4SFP+ 370W Switch.
- Network Ports : 48x 1 Gigabit Ethernet Class 4 PoE RJ-45 - Supports PoE Standards IEEE 802.3af, 802.3at
- Uplink Ports : 4x 10 Gigabit Ethernet SFP+ (Also used as Stacking Ports)
- Management Ports : 1x USB-C Console Port, 1x OOBM, 1x USB Type-A Host port, 1x RJ-45 Console Port
- Stacking Ports : Ses "Uplink Ports"
- Stack Size : 8 members (with other 24/48p 6200F and 6200M switches only)
- Stacking Bandwidth : 40Gbps
- CPU : Quad Core ARM Cortex™ A72 @ 1.8 GHz
- Packet Buffer : 8 MB Packet Buffer Memory
- Fan Module Options : Fixed
- Power Supplies Included : Fixed
- PoE Budget : Up to 370W of Class 4 PoE Power
- Switching Capacity : 176 Gbps
- Forwarding Rate : Up to 130.9Mpps
- MAC Address Table Size : 32,768
- Latency : 1 Gbps = 2.28 μSec, 10 Gbps =1.46 μSec
- DRAM and Flash : 8 GB DDR4 16 GB eMMC
- Model Number : JL727B
- Part Number : JL727B
- Condition : New
- One (1) NEW HPE Aruba JL727B 48x 1GB Class 4 PoE RJ-45 4x 10GB SFP+ Switch as described above
