The Cisco Meraki MX84-HW is a 1U rack-mount security and SD-WAN appliance managed from the Meraki Dashboard. It has two dedicated Gigabit RJ-45 WAN ports, eight Gigabit RJ-45 LAN ports, and two Gigabit SFP LAN ports, plus a dedicated management port and a USB port for a cellular modem used as failover.
Meraki rates it at 500 Mbps stateful firewall throughput in NAT mode, 250 Mbps maximum VPN throughput, and 320 Mbps with advanced security enabled. It is sized for a medium branch with up to 200 devices.
The power supply is internal, rated for 100-220V AC, and the appliance draws 26W idle and 32W at full load, so no external adapter is needed. The chassis is 19 inches wide, 10 inches deep, and 1.75 inches high and weighs 9 lb. The SFP ports take fiber or copper SFP modules for a link to a core switch. The appliance is sold unclaimed; a Meraki license is required, purchased separately.
For a Gigabit fiber link, the MA-SFP-1GB-SX multimode SFP fits the SFP ports. For twice the firewall throughput in the same 1U format, see the MX85-HW, and for 10 Gigabit SFP+ ports, the MX95-HW.
This seller refurbished Cisco Meraki MX84-HW security appliance is tested, working, and covered by the NetworkTigers one-year warranty.
- Network Ports : 8x 1 Gigabit RJ-45 LAN, 2x 1 Gigabit SFP LAN
- Uplink Ports : 2x 1 Gigabit RJ-45 WAN
- Management Ports : 1x RJ-45 management, 1x USB (cellular modem for failover)
- Module Slots and Options : SFP optics sold separately
- AC Power Included : Yes - internal 100-220 VAC, 50-60 Hz
- Stateful Throughput : 500 Mbps (320 Mbps advanced security)
- VPN Throughput : 250 Mbps
- Licenses and SSL VPN : Unclaimed - Meraki MX license required, sold separately
- Rack Mount Hardware : 1U rack mount
- Model Number : MX84-HW
- Part Number : MX84-HW, MX84-HW=, MX84-HW-WS
- Condition : Seller refurbished
- One (1) Seller Refurbished Cisco Meraki MX84-HW 500 Mbps 10x 1GB RJ45 2x 1GB SFP Unclaimed Firewall as described above
- One (1) Power Cord Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
- License is not included. This is sold directly by Meraki
