The NEW Extreme AP305C-FCC is an indoor Wi-Fi 6 access point. With internal antennas and options for additional external antennas, this device operates on both the 2.4 GHz and 5.0 GHz frequencies to deliver high-speed wireless connectivity.
This product delivers efficient and secure connections while offering scalability as your network grows. Enhance your wireless capabilities with the Extreme AP305C-FCC Indoor Wi-Fi-6 Access Point.
NEW Extreme AP305C-FCC AP305 Series Indoor Wi-Fi 6 US WAP w/ Internal Antennas
- Wi-Fi Standard : Wi-Fi 6 - EEE 802.11a/b/g/n/ac/ax
- Managed By : Cloud platform, or on-premises via a controller appliance or distributed operating system, dual-persona firmware selectable at boot or later
- Suggested Use : Budget-conscious enterprises needing high-density indoor Wi-Fi 6 performance without sacrificing features, general indoor deployment
- Region : US
- Radios : 2x, one 2.4GHz and one 5GHz, with software-selectable radio modes allowing fixed dual-band or dual 5GHz operation
- Spatial Streams per Radio : 2x streams on both 2.4GHz and 5GHz using 2x2 by 2, for 4x total combined
- Maximum Data Rate : Up to 574 Mbps on 2.4GHz and 1200 Mbps on 5GHz, up to 2.4 Gbps concurrently across both radios
- Bluetooth / IoT Radios : Integrated Bluetooth Low Energy radio, note a non-BLE variant of this SKU exists with identical functionality otherwise
- PoE Standard : 802.3af required for full functionality, USB port draws additional power beyond 500mA requiring 802.3at
- Uplink Ports : 1x 10/100/1000 Base-T Ethernet, PoE (802.3af) RJ-45
- Other Ports : 1x USB 2.0, Type A, 5V, 0.9A
- Antenna Type : Integrated internal antennas, 3x dual-band 2.4/5GHz omnidirectional plus 1x single-band 5GHz omnidirectional, peak gain 2.67dBi (2.4GHz) and 3.75-3.97dBi (5GHz)
- Mounting Options : Wall mount, junction box/wall mount, beam mount, or various ceiling grid brackets, all sold separately, plus a built-in Kensington lock slot
- Mounts Included : Built-in ceiling mount clips for 15/16 in flush ceiling tile rail systems, integrated directly into the AP,
- Model Number : AP305C-FCC
- Part Number : AP305C-FCC, AP 305C-FCC
- Condition : New
- One (1) NEW Extreme AP305C-FCC Wi-Fi 6 802.11ax US Internal Omni Dir Antennas Indoor WAP as described above
